(2) Program editing
Click the "Edit" button in the "program selection interface" to pop up the
program editing interface as shown in the following figure.
Name
NO
Time(min)
Vac(mbar)
After setting the parameters, press the program number to be saved until
the upper part of the interface indicates "save". As shown in the figure.
Note:
If the set vacuum value or timing is blank, it indicates that the current step
Program editing area
Fig. 3.2.7
Function introduction
Sequence No. of program execution
Timing time, set within a range of 0-5999min
Set the vacuum value within a range of 1 - local
atmospheric pressure (P0)
Table 8
Indicates "save"
Fig. 3.2.8
11
Program No.
selection button
