Edwards D372-15-805 Instruction Manual

Edwards D372-15-805 Instruction Manual

Usb / rs232 & slta-10 / lon
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USB / RS232 & SLTA-10 / LON
Description
USB Pump RS232 Interface Kit
SLTA-10 Pump LON Interface Kit
© Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Instruction Manual
D372-15-860 Issue Draft 1
D372-15-860
Issue Draft 1
Item Number
D372-15-805
D372-15-810
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D372-15-805 and is the answer not in the manual?

Questions and answers

Related Manuals for Edwards D372-15-805

Summary of Contents for Edwards D372-15-805

  • Page 1 USB / RS232 & SLTA-10 / LON Description Item Number USB Pump RS232 Interface Kit D372-15-805 SLTA-10 Pump LON Interface Kit D372-15-810 © Edwards Limited 2011. All rights reserved. Page 1 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 2: Table Of Contents

    2.2.4 Certifications..............11 Installation ................12 Unpack and inspect ............... 12 Install the D372-15-805 USB Pump RS232 Interface Kit ..... 13 Install the D372-15-810 SLTA-10 Pump LON Interface Kit....15 Operation ................24 Maintenance and Safety.............. 24 Inspect the connections............30 Communication problems............

  • Page 3: Introduction

    Edwards interface kits: D372-15-805 USB Pump RS232 Interface Kit • o to connect a PC’s USB port to an Edwards pump’s RS232 port D372-15-810 SLTA-10 Pump LON Interface Kit • o to connect a user-provided SLTA-10 to an Edwards pump’s LON port Read this manual before you install and operate either of those kits.

  • Page 4: Description

    1.2.1 D372-15-805 USB Pump RS232 Interface Kit The main component of this kit is D49951139, and Edwards cable assembly with a PC USB TYPE A plug at one end and a pump RS232 5-way XLR plug at the other end.

  • Page 5: D372-15-810 Slta-10 Pump Lon Interface Kit

    D372-15-860 Issue Draft 1 The primary purpose for this kit is to allow an Edwards pump with an RS232 interface to be supported using various Edwards PC software tools such as EST (Edwards Support Toolkit), FEUU (Flash EPROM Upgrade Utility) and others. So, the final component of this kit is D37215870, an Edwards CD-ROM containing FTDI USB drivers for the Windows operating- system, along with this instruction manual.
  • Page 6 D372-15-860 Issue Draft 1 There are several variants of the SLTA-10. The one required for use with Edwards pumps is “SLTA-10/TP-78 Serial LonTalk Adapter” and the Echelon part number is “73352R”. It is very important to purchase that specific variant, which is the only one that has the “TP-78”...
  • Page 7 Remove these locking screws The sole purpose for this kit is to allow an Edwards pump with a LON interface to be supported via an SLTA-10 using various Edwards PC software tools such as EST, FEUU and others. So, the final component of this kit is D37215870, an Edwards CD-ROM containing Echelon LON drivers and associated utilities for the Windows operating-system, along with this instruction manual.

  • Page 8: Interface Kit Summary

    D372-15-860 Issue Draft 1 1.2.3 Interface Kit Summary If you need to run Edwards PC software tools to support a Gen 1 pump (iQ or Mk1 iH) then you must connect the PC to the pump via its LON interface. The currently preferred...

  • Page 9: Technical Data

    Pin 5: n/c 2.1.2 Operating Temperature 0° to +60°C 2.1.3 Cable UL2464, 24 AWG, 5mm diameter 1.8m length 2.1.4 Certifications RoHS © Edwards Limited 2011. All rights reserved. Page 9 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 10: D372-15-810 Slta-10 Pump Lon Interface Kit

    D372-15-860 Issue Draft 1 The active part of the D372-15-805 USB Pump RS232 Interface Kit is a USB adapter cable assembly manufactured by FTDI: their part number is USB-RS232-WE-1800-BT Edwards adds the 5W XLR connector to that FTDI product, which is already CE marked and meets European and FCC EMC standards.

  • Page 11: Electrical

    1.8m length 2.2.4 Certifications RoHS NOTE: The Edwards SLTA-10 Pump LON Interface Kit contains no active parts. This kit needs to be used in conjunction with a user-supplied USB RS232 adapter, such as those recommended from FTDI, and an Echelon SLTA-10 RS232 LON adapter.

  • Page 12: Installation

    D49951141 2xWeidmuller 4W XLR, SLTA-10 to Pump Lon cable assembly 500003076 9W Sub-D gender changer D37215870 Drivers and instruction manual CD-ROM © Edwards Limited 2011. All rights reserved. Page 12 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 13: Install The D372-15-805 Usb Pump Rs232 Interface Kit

    The CD-ROM contains the latest (as of Dec 2011) FTDI driver software for the Windows XP and Windows 7 operating-systems, 32-bit (x86) and 64-bit (x64) versions. Edwards PCs generally have Windows XP 32-bit (x86) installed but from January 2012 new Edwards PCs will come with Windows 7 64-bit (x64) installed.
  • Page 14 23, but your system is likely to assign a different COM port number. Make a note of the COM port number, for use later when configuring the communications settings of Edwards PC software support tools. © Edwards Limited 2011. All rights reserved. Page 14 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 15: Install The D372-15-810 Slta-10 Pump Lon Interface Kit

    Plug the XLR end of the D49951139 USB 5W XLR, PC to Pump RS232 cable into an Edwards pump with a compatible 5W XLR RS232 / PDT socket. Make use of the kit’s D37370726 adapter if the Edwards pump has a compatible RJ12 RS232 / PDT socket.
  • Page 16 The following sequence of installation wizard boxes will then appear when the appropriate Next, Install etc. buttons are clicked. © Edwards Limited 2011. All rights reserved. Page 16 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 17 153-0409-01A_slta10_Windows.exe Click on the next dialog box which will result in this dialog box appearing. © Edwards Limited 2011. All rights reserved. Page 17 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 18 The following sequence of installation wizard boxes will then appear when the appropriate Yes, Next etc. buttons are clicked. © Edwards Limited 2011. All rights reserved. Page 18 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 19 SLTALink Manager utility, either by double-clicking the icon in the Windows system tray or via the Start menu. Link Select/Action… Select © Edwards Limited 2011. All rights reserved. Page 19 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 20 D372-15-860 Issue Draft 1 Edit… Click the button © Edwards Limited 2011. All rights reserved. Page 20 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 21 1 2 3 4 5 6 7 8 Read the label on the underside of the user-supplied SLTA-10 for the meaning of the switch settings. © Edwards Limited 2011. All rights reserved. Page 21 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 22 Use the D49951141 2xWeidmuller 4W XLR, SLTA-10 to Pump Lon cable assembly to connect the SLTA-10 directly into an Edwards pump with a compatible 4W XLR LON socket. Apply power to the pump and confirm that the SLTA-10 is powered on, as indicated by its green LED, next to the black Weidmuller connector, being illuminated.
  • Page 23 Weidmuller connector for ten seconds then re-inserting it), then re-start SLTALink Manager and try connecting again by clicking the button. See Section 4 for tips on operation with Edwards PC software support tools. © Edwards Limited 2011. All rights reserved. Page 23...

  • Page 24: Operation

    Once the USB Pump RS232 Interface Kit and/or SLTA-10 Pump LON Interface Kit have been installed, as described in Section 3, they are intended to be operated with Edwards PC software support tools. Users should familiarise themselves with the specific instructions associated with the relevant software tool.
  • Page 25 PLF over serial Select then click Select the relevant COM port number (the one that Windows has assigned to the Edwards Serial port to use Maximum RS232 adapter) from the drop-down box and set the baud rate to use to 57600.
  • Page 26 COM port number (the one that Windows has assigned to the Edwards USB RS232 adapter), tick the Enable checkbox and click the button. © Edwards Limited 2011. All rights reserved. Page 26 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 27 Options change the Latency Timer (msec) remains set to 2. Then click OK to close Advanced… and click OK again to close Port Settings. 4.2 Using SLTA-10 Pump LON Interface Kit with Edwards PC tools 4.2.1 CDU CDU does not support a LON interface to the pump. CDU can only be used with an RS232 interface to the pump.
  • Page 28 If the Detected Equipment display does not immediately indicate that LON communication has started try re-starting EST. © Edwards Limited 2011. All rights reserved. Page 28 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 29 Then restart FEUU. FEUU should immediately recognise the SLTA-10 is present and start the LON communications without requiring any further configuration. © Edwards Limited 2011. All rights reserved. Page 29 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 30: Inspect The Connections

    System Hardware is plugged in? Device Manager Ports (COM & LPT) and verify that you can see USB Serial Port (COMn). © Edwards Limited 2011. All rights reserved. Page 30 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 31: Fault Finding The Slta-10 Pump Lon Interface Kit

    PC? flash then the USB RS232 adapter may be faulty. Try it on a different PC. Continued on the next page… © Edwards Limited 2011. All rights reserved. Page 31 Edwards and the Edwards logo are trademarks of Edwards Limited.
  • Page 32 EST or FEUU, and confirm that it is as the Lon adapter’s open string? configured to use SLTALON1 Lon adapter’s open string. © Edwards Limited 2011. All rights reserved. Page 32 Edwards and the Edwards logo are trademarks of Edwards Limited.

  • Page 33: Storage And Disposal

    When required for use, install the interface kits as described in Section 3. 6.2 Disposal Edwards interface kits or any of their components must be disposed of safely in accordance with all local and national safety and environmental requirements.

  • Page 34: Abbreviations

    Short for LonWorks, an Echelon brand name for their industrial network standard, which was adopted by Edwards for use in the iQ (Gen 1), iH (Gen 2) and iGX (Gen 3) families of pumps. It was dropped for iXH / iXL (Gen 4) pumps.
  • Page 35 XLR has become a de facto standard for a family of connectors widely used in the audio industry due to their robust metal housings and latching mechanism. Edwards pumps tend to have a 4-way XLR socket for LON and/or a 5-way XLR socket for RS232 / PDT.
