Denver - 1 Drawer Bedside
Assembly Instructions -
Dimensions
Width - 41cm
Depth - 40cm
Height - 49cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
352/9045
357/9040
339/5846
MADE IN
BRITAIN
Issue 1 - 20/10/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Denver 352/9045
Summary of Contents for Argos Denver 352/9045
- Page 1 Denver - 1 Drawer Bedside Assembly Instructions - 352/9045 Please keep for future reference 357/9040 339/5846 Dimensions Width - 41cm Depth - 40cm MADE IN Height - 49cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 20/10/14...
-
