Capella - 3+2 Drawer Chest
Assembly Instructions -
Dimensions
Width - 63cm
Depth - 39cm
Height - 75cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
357/7097
339/2344
330/7559
MADE IN
BRITAIN
Issue 1 - 28/11/14
Advertisement
Related Manuals for Argos 357/7097
Summary of Contents for Argos 357/7097
- Page 1 Capella - 3+2 Drawer Chest Assembly Instructions - 357/7097 Please keep for future reference 339/2344 330/7559 Dimensions Width - 63cm Depth - 39cm MADE IN Height - 75cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 24kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below 3 Top (DF1848A) Left Side Rail (D1039A) Right Side (D1009A) (D1040A) (596 x 369mm) (744 x 390mm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer fronts Screw 2 metal dowels into the holes shown on the back of each large drawer front Note: Tighten the metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 Fit the large drawer base Slide the large drawer base down the grooves in the drawer sides down into the groove in the large drawer front . Step 5 Fit the large drawer back Fit the large drawer back between the drawer sides Make sure that the...
- Page 7 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 8 Note: The small right drawer front has a shallow identification mark. Prepare the 2 small drawer fronts Screw 2 metal dowels into the small left drawer front and the small...
- Page 8 Assembly Instructions Step 11 Fit the small drawer base Slide the small drawer base down the grooves in the drawer sides down into the groove in the small drawer fronts Step 12 Fit the small drawer back Fit the small drawer back between the drawer sides Make sure that the small...
- Page 9 Assembly Instructions Step 15 Prepare the left side Place 4 runners the left side . Slide back the top of the Profiled front edge runner and use the 1st hole from the front to fit the 1st screw Slide the runner back Profiled the other way and use front edge...
- Page 10 Assembly Instructions Step 16 Prepare the right side Place 4 runners the right side . Slide back the top of the runner and use the 1st hole from the front to fit the 1st screw Profiled front edge Slide the runner back the other way and use the 3rd hole from the back to fit the 2nd screw...
- Page 11 Assembly Instructions Step 17 Prepare the top Tap 4 wooden dowels into the top shown. Note: Wooden dowels 10mm must not stick out from the edge by more than 10mm or they may damage other panels. Insert 4 large locking Finished nuts into the top...
- Page 12 Assembly Instructions Step 19 Note: Due to the manufacturing process, the 2 holes for Prepare the divider the large locking nut can be on either surface of the divider. Place a runner the divider as shown. Slide back the top of runner and use the 1st hole from the front to fit the 1st screw...
- Page 13 Assembly Instructions Step 21 Join the right side and Push the top onto the right side shown. Use a screwdriver to tighten the 2 large locking nuts fitted to the top Profiled Finished Note: Turn the large front front edge locking nuts as far as edge...
- Page 14 Assembly Instructions Step 23 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the top and the rails Step 24 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by...
- Page 15 Assembly Instructions Step 25 Fit the drawers Starting with the bottom drawer, slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2 screws...
- Page 16 Screw type. Washer If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3120...
