Asha - Cabin Bed
Assembly Instructions
356/3018
- Please keep for future reference
379/7482
Dimensions
Width - 195cm
Depth - 95cm
Height - 45cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0345 6400800
Issue 1 - 9/30/13
Advertisement
Related Manuals for Argos 356/3018
Summary of Contents for Argos 356/3018
- Page 1 Asha - Cabin Bed Assembly Instructions 356/3018 - Please keep for future reference 379/7482 Dimensions Width - 195cm Depth - 95cm Height - 45cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • To reduce components and tools listed on the product, this could cause the likelihood of pages 2 and 3. - Page 3 Components - Panels If you have damaged or missing components, 0345 6400800 call the Customer Helpline: Please check you have all the panels listed below Front/back bed support x4 (73 x 7 cm) Right side panel (95 x 42.5 cm) Middle bed board (95 x 64.5 cm) Left side panel...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 50mm wood screw x 14 50mm fixing screw x 28 30mm wooden dowel x 20 Locking nut x 6...
- Page 5 Assembly Instructions Step 1 Assemble right module Two people are needed here. Insert 3 pieces 30mm wooden dowels into right side panel 3 pieces 30mm wooden dowels into right shelf partition Position the boards like shown on the picture. Use 3 pieces 50mm wood screws fix the right central Clockwise...
- Page 6 Assembly Instructions Step 2 Assemble left module Two people are needed here. Insert 3 pieces 30mm wooden dowels into left side panel and 3 pieces 30mm wooden dowels into left shelf partition Position the boards like shown on the picture. Use 3 pieces 50mm wood screws to fix...
- Page 7 Assembly Instructions Step 3 Attaching panels Two people are needed here. Insert 3pcs 30mm wooden dowels the left shelf partition and 3pcs 30mm wooden dowels to the right shelf partition . Insert 3pcs screw-in dowels to the left shelf partition and 3pcs screw-in dowels to the right...
- Page 8 Assembly Instructions Step 4 Attaching panels Two people are needed here. Insert the 30mm dowels to the left side panel and to the right side panel like shown on the drawing. Position the left and the right bed boards Note: Position of wooden dowels on the right side panel...
- Page 9 Assembly Instructions Step 4 - continued Position the middle bed board and screw it to the middle central Clockwise support through 50mm fixing screw Use the Allen key the 50mm fixing screw Screw the middle bed board , the left bed board and the right bed board...
- Page 10 Assembly Instructions Step 6 Attaching panels First screw the front and the back bed supports to the right side panel and to the left side panel through 50mm wood screw . After that screw the left and the right bed boards the left side panel to the right side panel through 50mm wood...
- Page 11 Assembly Instructions Step 8 Attaching door Insert the hinges and screw them to the door through 16mm wood screw . Use the pilot holes. Position the handle and fix it to the door through 30mm wood screw Position the mounting plates onto the right shelf partition...
- Page 12 Assembly Instructions Step 9 - continued To move the door in or out: loosen screw shown and move the door to suit. Re-tighten screw. To move the door left or right: loosen or tighten the screw shown and move the door to suit. Step 9 Attaching stopper Insert the stopper...
