Arvika - 2 Drawer 2 Door Robe

Assembly Instructions -

Dimensions

Width - 83cm

Depth - 49.5cm

Height - 186.5cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

357/6823

356/4921

MADE IN

BRITAIN

Issue 2 - 16/12/14

Need help?

Do you have a question about the Arvika 357/6823 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Arvika 357/6823

Page 1 Arvika - 2 Drawer 2 Door Robe Assembly Instructions - 357/6823 Please keep for future reference 356/4921 Dimensions Width - 83cm Depth - 49.5cm MADE IN Height - 186.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 2 - 16/12/14...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 52.5kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Top Drawer Front (DF1886) (791 x 161mm) (DF919) (829 x 495mm) Top Left Drawer Side (W370-124LH)
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the top drawer front Screw 2 metal dowels into the back of the top drawer front Note: Tighten the metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the top drawer sides and down into the groove in the top drawer front Step 5 Fit the top drawer back Fit the top drawer back between the top drawer sides Make sure that the...
Page 7 Assembly Instructions Step 7 Fit the wedgefixes Turn the top drawer assembly over and slide 4 wedgefixes into the front and back grooves, as shown, and tighten up the screws. Step 8 Runners must be pushed up against Fit the runners the drawer front Fit a runner marked with ‘R’, to the...
Page 8 Assembly Instructions Step 9 Prepare the bottom drawer front Screw 2 metal dowels into the bottom drawer front Note: Tighten the metal dowels up fully against the panels. Step 10 Prepare the bottom drawer sides Insert a small locking into the hole shown on the bottom left drawer side and the...
Page 9 Assembly Instructions Step 12 Fit the drawer base Slide the drawer base down the grooves in the bottom drawer sides and down into the groove in the bottom drawer front Step 13 Fit the bottom drawer back Fit the bottom drawer back between the bottom drawer sides...
Page 10 Assembly Instructions Step 15 Fit the wedgefixes Turn the bottom drawer assembly over and slide 4 wedgefixes into the front and back grooves, as shown, and tighten up the screws. Step 16 Runners must be Fit the runners pushed up against the drawer front Fit a runner marked with ‘R’, to the...
Page 11 Assembly Instructions Step 17 screw screw screw Prepare the left side Fit 2 runners the left side The 1st screw uses Finished the 1st hole in from the front edge front of the runners. The 2nd and 3rd screws use the holes that line up with the other panel holes.
Page 12 Assembly Instructions Step 18 screw screw screw Prepare the right side Fit 2 runners the right side The 1st screw uses the 1st hole in from the front of the runners. The 2nd and 3rd screws use the holes that line Finished up with the other panel front edge...
Page 13 Assembly Instructions Step 19 Prepare the horizontal Insert 4 large locking nuts into the horizontal Finished Note: The arrow on the front edge locking nut must point towards the hole in the edge of the panel. Tap 4 wooden dowels into the horizontal Step 20 Fit the right side to...
Page 14 Assembly Instructions Step 22 Note: The top panel has been finished on Fit the top both surfaces. The base panel only Attach the top to the has 1 finished suface. left side and right side using 4 screws Finished front edge Step 23 Fit the base Attach the base...
Page 15 Assembly Instructions Step 24 Fit the feet Attach the 4 feet the base using 4 screws Step 25 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that...
Page 16 Assembly Instructions Step 26 Fit the drawers and hanging rail Push the hanging rail into the rail holders Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push the drawers into position.
Page 17 Assembly Instructions Step 28 Fit doors and handles Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 18 Assembly Instructions Step 29 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 19 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
Page 20 ALR3115...
