Arvika - 4 Drawer Chest

Assembly Instructions -

Dimensions

Width - 72cm

Depth - 39.5cm

Height - 89.5cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

356/4536

339/0281

MADE IN

BRITAIN

Issue 1 - 13/11/13

Need help?

Do you have a question about the Arvika 356/4536 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Arvika 356/4536

Page 1 Arvika - 4 Drawer Chest Assembly Instructions - 356/4536 Please keep for future reference 339/0281 Dimensions Width - 72cm Depth - 39.5cm MADE IN Height - 89.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 13/11/13...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 28.5kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (DF914) (716 X 394mm) Left Side Right Side Base (DF912) (DF1441) (DF1963) (743 x 393mm)
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 3 small drawer fronts Screw 2 metal dowels into each of the small drawer fronts Note: Tighten the metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the small drawer sides and down into the groove in the small drawer front Step 5 Fit the small drawer back Fit the small drawer back between the small drawer sides Make sure that the...
Page 7 Assembly Instructions Step 7 Fit the wedgefixes Turn the drawer assemblies over and slide 4 wedgefixes into the front and back grooves, as shown, and tighten up the screws. Step 8 Runners must be Fit the runners pushed up against the drawer front Fit a runner marked with ‘R’, to the...
Page 8 Assembly Instructions Step 9 Prepare the large drawer front Screw 2 metal dowels into the large drawer front Note: Tighten the metal dowels up fully against the panels. Step 10 Prepare the large drawer sides Insert a small locking into the hole shown on the large left drawer side and the...
Page 9 Assembly Instructions Step 12 Fit the drawer base Slide the drawer base down the grooves in the large drawer sides and down into the groove in the large drawer front Step 13 Fit the large drawer back Fit the large drawer back between the large drawer sides Make sure that the...
Page 10 Assembly Instructions Step 15 Fit the wedgefixes Turn the drawer assembly over and slide 4 wedgefixes into the front and back grooves, as shown, and tighten up the screws. Step 16 Runners must be Fit the runners pushed up against the drawer front Fit a runner marked with ‘R’, to the...
Page 11 Assembly Instructions Step 17 screw screw screw Prepare the left side Fit 4 runners the left side The 1st screw uses the 1st hole in from the front of the runners. Finished front edge The 2nd and 3rd screws use the holes that line up with the other panel holes.
Page 12 Assembly Instructions Step 18 screw screw screw Prepare the right side Fit 4 runners the right side The 1st screw uses the 1st hole in from the front of the runners. The 2nd and 3rd screws use the holes that line up with the other panel holes.
Page 13 Assembly Instructions Step 19 Prepare the top Screw 4 metal dowels into the top Note: The top panel has been finished on both surfaces. The base panel has 1 chipboard suface. Finished front edge Step 20 Fit the sides to the Push the left side and right side onto...
Page 14 Assembly Instructions Step 21 Fit the base Attach the base the sides using the 4 screws p l a c h i s u r f a c Finished front edge Step 22 Note: The raised part Fit the leg brackets to of the leg bracket must the base point towards the...
Page 15 Assembly Instructions Step 23 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
Page 16 Lift with care. Side panel Drawer If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3113...
