NetPing Input+Relay R404 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

[ENG] NetPing Input+Relay R404, User guide


Advertisement

Table of Contents
loading

Related Manuals for NetPing Input+Relay R404

Summary of Contents for NetPing Input+Relay R404

  • Page 1   [ENG] NetPing Input+Relay R404, User guide  ...

  • Page 2: Table Of Contents

    [ENG] NetPing Input+Relay R404, User guide - Содержание   [ENG] 1. [DKST 57]Introduction.................. 5 [ENG] 2. [DKST 57]Copyright and Disclaimer............. 6 [ENG] 3. [DKST 57]Shipping Kit .................. 7 [ENG] 4. [DKST 57]Device overview and main features..........8 General view of the device......................... 8 Front panel ............................
  • Page 3 [ENG] NetPing Input+Relay R404, User guide - Impact sensor................................... 24 PIR detector (mod.M105-1E)............................25 External loads for RELAYS........................ 26 Buzzer (mod.STD-3025) ........................27 Airflow sensor + GRID 120 * 120 * 10mm NC ................... 28 Smoke detector (mod. M206-5E)..................... 28 [ENG] 8.
  • Page 4 [ENG] NetPing Input+Relay R404, User guide - • [ENG] 1. [DKST 57]Introduction • [ENG] 2. [DKST 57]Copyright and Disclaimer • [ENG] 3. [DKST 57]Shipping Kit • [ENG] 4. [DKST 57]Device overview and main features • [ENG] 5. [DKST 57]Sockets and Indication Elements •...

  • Page 5: [Eng] 1. [Dkst 57]Introduction

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 1. [DKST 57]Introduction [ENG] 1. [DKST 57]Introduction This user guide helps to become familiar with an operation of a NetPing Input+Relay R404 device and get an idea about its functionality and technical specifications as well as prepare a device for an operation.

  • Page 6: [Eng] 2. [Dkst 57]Copyright And Disclaimer

    All copyrights on supplied devices, described in this User Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Copying, replication and translation of this user guide to other languages are not allowed without a prior written permission of a rightholder.

  • Page 7: [Eng] 3. [Dkst 57]Shipping Kit

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 3. [DKST 57]Shipping Kit [ENG] 3. [DKST 57]Shipping Kit Supply package If any of the items listed below are missing, contact the seller: • NetPing Input+Relay R404 — 1 pc.; • a screw driver — 1 pc.;...

  • Page 8: [Eng] 4. [Dkst 57]Device Overview And Main Features

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 4. [DKST 57]Device overview and main features [ENG] 4. [DKST 57]Device overview and main features A device for remote monitoring of sensors over an Ethernet/Internet network on the mounting rail of compatible DIN 43880-1988 devices. Allows you to remotely receive information about the status of sensors and notifications about sensor activation, manage connected devices. ...

  • Page 9: Back View

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 4. [DKST 57]Device overview and main features  Back view Side view Device mounting method Mounting is carried out on a rail compatible with DIN 43880-1988 [ENG] 4. [DKST 57]Device overview and main features...

  • Page 10: General Characteristics

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 4. [DKST 57]Device overview and main features Installation of the device is carried out in an industrial-type cabinet, which ensures the absence of moisture and condensation in the working space, and also carries out the forced outflow of excess heat...
  • Page 11 [ENG] NetPing Input+Relay R404, User guide -[ENG] 4. [DKST 57]Device overview and main features Parameter Value 1 pcs. Connector for connecting the battery DK ST P20J1L-04 - 1 pcs. SNMP control SNMP v1 SNMP TRAP notifications SNMP v1/v2 Input lines...

  • Page 12: [Eng] 5. [Dkst 57]Sockets And Indication Elements

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 5. [DKST 57]Sockets and Indication Elements [ENG] 5. [DKST 57]Sockets and Indication Elements Front panel [ENG] 5. [DKST 57]Sockets and Indication Elements                              – ...

  • Page 13: Connectors On The Bottom Of The Device

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 5. [DKST 57]Sockets and Indication Elements Connectors on the bottom of the device [ENG] 5. [DKST 57]Sockets and Indication Elements                              – ...

  • Page 14: Connectors On The Top Of The Device

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 5. [DKST 57]Sockets and Indication Elements Connectors on the top of the device Element Function Front panel ETH1 2x10 / 100 BASE-TX, 2 ports are unmanaged L2 switch LINK Ethernet port indicator: •...
  • Page 15 [ENG] NetPing Input+Relay R404, User guide -[ENG] 5. [DKST 57]Sockets and Indication Elements Indicator CPU on the ETH1 Device operation indicator: • continuously lit if the device is powered; • blinks 5-6 times when the device is turned on (during the firmware download process);...
  • Page 16 [ENG] NetPing Input+Relay R404, User guide -[ENG] 5. [DKST 57]Sockets and Indication Elements OUT 1..4 Discrete outputs with the function OUT-UP 12V up to 200mA, OUT-DOWN GND up to 200mA. The total load on the outputs in the OUT-UP mode should not exceed 250mA. Each output is protected from short-circuit by a self-healing 250mA fuse.

  • Page 17: [Eng] 6. [Dkst 57]Connection, Installation And Initial Configuration Of The Device

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 6. [DKST 57]Connection, installation and initial configuration of the device [ENG] 6. [DKST 57]Connection, installation and initial configuration of the device Step 1 Take the device out of the package Step 2 Install it in its place of permanent residence.

  • Page 18: Step 4

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 6. [DKST 57]Connection, installation and initial configuration of the device If available, connect an external battery module to the device. The correct operation of the device can be determined by the operation of the CPU indicator - it should blink 5-6 times and light up continuously.

  • Page 19: Step 6

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 6. [DKST 57]Connection, installation and initial configuration of the device • Gateway: 0.0.0.0 • Login: visor • Password: ping Thus, the initial connection to the device is possible only from one subnet (192.168.0.0/24).
  • Page 20 [ENG] NetPing Input+Relay R404, User guide -[ENG] 6. [DKST 57]Connection, installation and initial configuration of the device Step 6 Configure the operation of the device via the built-in WEB interface (See Description of the firmware). [ENG] 6. [DKST 57]Connection, installation and initial configuration of the device...

  • Page 21: [Eng] 7. [Dkst 57]Connection Of External Sensors And Actuators

    [ENG] 7. [DKST 57]Connection of external sensors and actuators. It is strictly forbidden to connect sensors and external modules to NetPing devices when the power is on! To configure the device and receive notifications from sensors, see the document "Description of the firmware"...

  • Page 22: Two-Wire Sensors (Discrete)

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 7. [DKST 57]Connection of external sensors and actuators. Two-wire sensors (discrete) Sensors and other signal sources that do not require additional the power supply or they are powered from other sources, and it is decoupled from the signal line, connected to the INPUT and GND terminals of the device. The polarity of the connection is important, unless otherwise explicitly stated in the documentation for the sensor.

  • Page 23: Leak Sensor

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 7. [DKST 57]Connection of external sensors and actuators. The sensor has two connectors on different sides 6p6c for connecting to a monitoring device and 4p4c for connecting a sensitive cable leak sensing cable WLC10.

  • Page 24: Impact Sensor

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 7. [DKST 57]Connection of external sensors and actuators. Colored wire Terminal Black (general) Red (N.C.) IN1 ... IN16 White (N.O.) IN1 ... IN16 Important! Sensors of the "dry contact" type: 220V presence sensor, leakage sensor and others are connected to the INPUT lines of the device.

  • Page 25: Pir Detector (Mod.m105-1E)

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 7. [DKST 57]Connection of external sensors and actuators. Important! Sensors of the "dry contact" type: 220V presence sensor, leakage sensor and others are connected to the INPUT lines of the device. You can connect any 16 sensors from this set.

  • Page 26: External Loads For Relays

    RELAY "Off" - voltage is present at the outlet To switch the load in NetPing AC / DIN, a relay with normally closed contacts is used. This means that if the control wire is not connected anywhere, 220V will be present at the outlet, and the load will be turned on.

  • Page 27: Buzzer (Mod.std-3025)

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 7. [DKST 57]Connection of external sensors and actuators. Buzzer (mod.STD-3025) Colored wire Terminal White One of the OUT lines - 1 - 4 (in the "output" mode, log. 1) Colored A logic level on the OUT line, used for power supply, will control the operation of the siren. When log. 1 - siren is active, when log.

  • Page 28: Airflow Sensor + Grid 120 * 120 * 10Mm Nc

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 7. [DKST 57]Connection of external sensors and actuators. The sensor comes with a non-detachable cable with lugs at the ends. The cable length can be increased by using cable 4 extender, 4m, which are connected in series into each other, or independently using any wire with a cable section of at least 0.4 mm2.
  • Page 29 [ENG] NetPing Input+Relay R404, User guide -[ENG] 7. [DKST 57]Connection of external sensors and actuators. The sensor comes with a non-detachable cable with lugs at the ends. The cable length can be increased by using cable 4 extender, 4m, which are connected in series into each other, or independently using any wire with a cable section of at least 0.4 mm2.

  • Page 30: [Eng] 8. [Dkst 57]Use Of In, Out And Relays Lines

    It is possible to use intermediate relays with a supply voltage from an external 12V source. A controlled NetPing AC / DIN socket can be used to connect to OUTPUT lines.
  • Page 31 [ENG] NetPing Input+Relay R404, User guide -[ENG] 8. [DKST 57]Use of IN, OUT and RELAYS lines. INPUT - line: Input impedance 3.92 kOhm-10 kOhm. • logic «1» voltage: > 8,3 В; • logic «0» voltage: < 3,7 В. Attention!!! The voltage on the input lines should not exceed 12 V.

  • Page 32: [Eng] 9. [Dkst 57]Factory Reset Device

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 9. [DKST 57]Factory reset device [ENG] 9. [DKST 57]Factory reset device The reset procedure returns all configurable device parameters to default values (IP and MAC addresses, access filters, username, password, etc.) to their default values. ...

  • Page 33: [Eng] 10. [Dkst 57]Precautions

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 10. [DKST 57]Precautions [ENG] 10. [DKST 57]Precautions The next information will allow users to avoid both injuries and damaging a device as well as connected equipment. • A device must be used only in a power supply network, indicated by a manufacturer. Using any other power supply types may lead to damaging a device;...

  • Page 34: [Eng] 11. [Dkst 57]Warranty

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 11. [DKST 57]Warranty [ENG] 11. [DKST 57]Warranty The manufacturer guarantees normal operation of the product within 24 months from the date specified on the warranty sticker if a buyer follows operating and storage conditions. Manufacturer warranty applies only to failure of a device which occurred because of defects in manufacturing process of products and components used.

  • Page 35: [Eng] 12. [Dkst 57]Additional Documents And Links

    [ENG] NetPing Input+Relay R404, User guide -[ENG] 12. [DKST 57]Additional Documents and Links [ENG] 12. [DKST 57]Additional Documents and Links Pages of devices on a manufacturer's website: http://www.netpingdevice.com/products/netping-input-relay-r404 Manufacturer's website: http://www.netpingdevice.com/ Technical support contacts: http://www.netpingdevice.com/support Telephone: +886-2-23121582 E-mail: support@netpingdevice.com [ENG] 12. [DKST 57]Additional Documents and Links...

  • Page 36: [Eng] 13. [Dkst 57]Backup Power Supply

    The module is installed as an external unit and is connected with a wire to the connector on the case of NetPing controllers. The batteries installed in the NetPing 85M2 module are charged when they are connected to a NetPing device and there is an external power supply.
