Merrick

Assembly Instructions

Dimensions

Width - 130cm

Depth - 40cm

Height - 72,7cm

Important

– Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline:

14-3E-177_02

- Please keep for future reference

Sideboard

184/6335

183/8587

0845 077 8888

Issue 1 - 14/06/19

Need help?

Do you have a question about the Merrick 184/6335 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Merrick 184/6335

Page 1 Sideboard Merrick Assembly Instructions - Please keep for future reference 184/6335 183/8587 Dimensions Width - 130cm Depth - 40cm Height - 72,7cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 077 8888 14-3E-177_02 Issue 1 - 14/06/19...
Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • To reduce the • Check you have all the • Do not stand or put weight on components and tools listed on the product, this could cause likelihood of damaging your the following pages.
Page 3 If you have damaged or missing commponents, Components - Panels call the Customer Helpline: 0845 077 8888 Please check you have all the panels listed below Left side panel x 1 Right side panel x 1 Top panel x 1 (40 x 53,7cm) (40 x 53,7cm) (130 x 40cm)
Page 4 Components - Fittings Please check you have all the fittings listed below Note : The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 6/30mm Wooden dowel x 6 8/30mm Wooden dowel x 18 Spanner 13mm x 1 Large locking nut x 20...
Page 5 Assembly Instructions Step 1 Attaching legs Position the leg shown on the picture, place the washer fix the nut T using the spanner. Repeat assembly for the remaining legs. Step 2 Preparation for the attaching of side panels and vertical partition panel Insert screws E into the drilled holes of the basa 4...
Page 6 Assembly Instructions Step 3 Side panels and vertical partition panel assembly Insert wooden dowels B into the drilled holes in side panels vertical partition panel 18 and place the side panels 1 , and vertical partition panel 18 onto the base 4 . Insert large locking nuts G into the drilled holes in side panels...
Page 7 Assembly Instructions Step 5 Note: You must ensure the sideboard is Attaching back panel square before attaching the back panel. Position back panels in position on the back of sideboard. Position nails 5 mm in from side edge of the back panels with distance 100 mm between each other.
Page 8 Assembly Instructions Step 7 Stick the self-adhesive caps V onto the holes as shown on the picture. Step 8 Fixing to wall It is recomended that the sideboard is fixed to a wall. Mark fixing hole onto wall. Drill a hole and insert a suitable wall plug.
Page 9 Assembly Instructions Step 9 Drawer assembly a: Insert screws into drawer fronts b: Insert wooden dowels into left and right drawer sides 21 22 c: Insert plastic dowels into left drawer side and drawer back and fix it together using the hammer. d: Insert plastic dowels into right drawer side...
Page 10 Assembly Instructions Step 9 - continued g: Align correctly and insert small locking nuts into left and right drawer sides 21 22 and turn them clockwise to lock. h: Position left and right runners to left and right drawer sides , fix using 21 22 screws...
Page 11 Assembly Instructions Step 11 Braces assembly Insert wooden dowels B into the drilled holes in braces and place them onto the shelf Insert large locking nuts into the drilled holes in braces and turn them clockwise to lock. Step 12 Placing shelf Position shelf supports and place the shelf...
Page 12 Assembly Instructions Step 13 Attaching sliding fittings Fit the upper and lower sliding fitting to door panel with screw 15 19 Do not tighten both fittings fully! Step 14 Setting up the door Start with right door Fit lower sliding fitting into the groove in the base , cover the upper...
Page 13 Assembly Instructions Step 15 Door adjusting Follow the pictures- adjust the level of the door Step 16 Once the door adjusted, secure with screws Repeat the steps 12 and 13 for the left door...
Page 14 Assembly Instructions Step 17 Backstop instalation CAREFUL! Insert the wooden dowel b into the back side of the left door Knob attaching Attach knob to both doors using bolt 15 19...
Page 15 Assembly Instructions Step 18 Inserting drawers Insert the drawers moving up and down as shown and ensure that wheels fit onto left and right runners Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 077 8888 Home Retail Group Plc, 489 - 499 Avebury Boulevard, Milton Keynes, MK9 2NW...
