Amy white bunk Trundle
- 190x90 cm
Assembly Instructions
1876965
- Please keep for future reference
Dimensions
Length - 186cm
Depth - 93cm
Height - 12cm
Weight - 11kg
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@fl exa.dk
Issue 1 - 15/05/14
Advertisement
Related Manuals for Argos Amy white bunk Trundle
Summary of Contents for Argos Amy white bunk Trundle
- Page 1 Amy white bunk Trundle - 190x90 cm Assembly Instructions 1876965 - Please keep for future reference Dimensions Length - 186cm Depth - 93cm Height - 12cm Weight - 11kg Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 or e-mail: order@fl...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • We do not • Check you have all the • Do not stand or put weight on recommend the components and tools listed on the product, this could cause use of power pages 2 and 3.
-
Page 3: Components - Parts
If you have damaged or missing components, Components - Parts call the Customer Helpline: 0045 7668 8055 Please check you have all the parts listed below Slat x13 (89.7x6.5x1.5cm) Slat x3 (90.0x6.5x1.5cm) No. 12-01508971 No. 12-01509001 Drawer back x1 (184.0x6.5x2.0cm) No. - Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. No. 4003-002 No. 3901-35030 No.
- Page 5 Assembly Instructions Step 1 920 mm 40 mm upside down Attach the slats to the drawer back and to the drawer front with screws Please make sure that all are in right angle (90 40 mm degrees) before you continue! 5 mm upside upside down...
- Page 6 Assembly Instructions Step 2 upside Attach the slats the drawer front the drawer back with screws...
- Page 7 Assembly Instructions Step 3 upside down Attach the castor wheels 40 mm 50 mm to the slats with the screws Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 E-mail: order@fl...
