esk
ssembly Instructions -
Dimensions
Width - 110.1 cm
Depth - 44.3 cm
Height - 81 cm
Important -
Please read these instructions fully before starting assembly
For enquiries relating to spare parts please contact : 08456 400800
Please keep for future reference
1866968
1866982
Ref. no NOR 10.00 ate: 26/06/11
Advertisement
Related Manuals for Argos 1866968
Summary of Contents for Argos 1866968
- Page 1 Instructions - 1866968 Please keep for future reference 1866982 Dimensions Width - 110.1 cm Depth - 44.3 cm Height - 81 cm Important - Please read these instructions fully before starting assembly For enquiries relating to spare parts please contact : 08456 400800...
- Page 2 Safety and care advice Important - Please read these intructions fully before starting assembly • Assemble the unit as close • Check you have all the • We do not components and tools listed on to its final position (in the same recommend the room) as possible.
- Page 3 Components - Panels Please check you have all the panels listed below Top x 1 (110.1 x 44.3cm) Left drawer Back drawer x 3 (36.85 x 14cm) side x 3 Back panel drawer x 1 (40 x 14cm) (43.9 x 73.6cm) Right drawer side x 3 (40 x 14cm)
- Page 4 For enquiries relating to spare parts please Components - Fittings contact : 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 30mm Long locking nut x 20...
- Page 5 Assembly Instructions Step 1 Preparation of side panels Fit wooden dowels A Fit metal dowels B Fit long locking nuts D Front Fix runner parts Z to the side panel through holes shown in the detail view using euroscrews Bottom and screws Fit support foot Front...
- Page 6 Assembly Instructions Step 2 Preparation of top and back panel desk Fit metal dowels a onto Fit long locking nuts b and wooden dowels A onto back panel Step 3 Attaching panels Important: Two people are needed here Fit metal dowels a onto right internal side Position structural plinth onto the...
- Page 7 Assembly Instructions Step 4 Attaching panels Important: Two people are needed here Position back panel desk 6 onto the side Use a screwdriver to turn locking nuts D clock- wise to lock. Step 5 Fix of top panel Position top panel 4 onto the side panels Use a screwdriver to turn locking nuts D clock-...
- Page 8 Assembly Instructions Step 6 Position back panel Step 7 Attach back panels Attach back panel using 30 nails G Important: Cabinet MUST be “square” when the back is attached...
- Page 9 Assembly Instructions Step 8 Wall fixing Important: two people are needed here. To prevent possible overbalancing we recommend that this unit is secured to a suitable wall. Secure one end of the Important: wall strap to the wall. Top of Unit Take care when drilling the wall that you do Thread the other end of...
- Page 10 Assembly Instructions Step 9 Assembling of drawer Fit the RH 14 and LH 13 drawer sides to the drawer backs 15 using 30 mm screws S Assembling drawer fronts Slide drawer bottom panels 11 into the drawer boxes grooves. Fit short locking nuts E to the drawer side panels 14 13 .
- Page 11 Assembly Instructions Step 11 Insert drawers Tilt the drawer as shown. Slide the drawer box along the runner parts until the stop. Wheels and runner parts have to be correctly matched as shown. That's the desk completed. Take care of your unit by using a damp cloth to clean it.
-
Page 12: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
