Seville - 5 Drawer Chest
Dimensions
Width - 66cm
Depth - 33cm
Height - 91cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0870 112 1928
or email: Help@ClickSpares.co.uk (quoting your original order number)
Please keep for future reference
184/9198
189/6385
145/0862
184/8319
MADE IN
BRITAIN
Issue 2 - 21/01/15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argos 184/9198
Summary of Contents for Argos 184/9198
- Page 1 Seville - 5 Drawer Chest Assembly Instructions - 184/9198 Please keep for future reference 189/6385 145/0862 184/8319 Dimensions Width - 66cm Depth - 33cm MADE IN Height - 91cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number)
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 21kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers below) Please check you have all the panels listed below Left Side Right Side (D2503A) (D2504A)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers below) Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers below) Step 1 Prepare the drawer Plain chipboard fronts surface Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal...
- Page 6 Assembly Instructions Step 4 Fit the drawer front Turn drawer wrap assembly over and push it onto the back of the drawer front Note: Turn the locking nuts clockwise to secure the panels - more than 1/2 a turn. Step 5 Attach the drawer stops Carefully break off 2...
- Page 7 Assembly Instructions Step 7 Finished Prepare the left side front edge F600 Separate the runners Push fit 5 left runners marked ‘L’ into the left side Note: Runners must be be fitted flat against the panel. If necessary gently tap into final position.
- Page 8 Assembly Instructions Step 10 Join the top to the right side Push the top onto the right side secure with 2 screws Finished Finished front edge front edge Step 11 Prepare the plinth Tap 2 wooden dowels into the plinth...
- Page 9 Assembly Instructions Step 12 Join the plinth to the right side Push the plinth onto the right side secure with screw Support the plinth until the left side has been fitted in the next step. Step 13 Fit the left side Push the left side onto the assembly and secure with 3 screws...
- Page 10 Assembly Instructions Step 14 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 11 Assembly Instructions Step 15 Insert the drawers Lift the front of the drawers whilst inserting to overcome the ‘stop’ system. Note: To ensure that your drawers run smoothly, spray a small amount of furniture polish into the grooves.
- Page 12 If you need help or have damaged or missing parts, call the Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers on the component pages) Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2910...
