- Page 1 OI WOW Eclipse Mirror Wall Cabinet 147/7584 40cm 15cm 50cm Issue 1 - 10/10/13...
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:08456 400800 Please check you have all the panels listed below Left side panel Back panel Right side panel Adjustable shelf Top panel Bottom panel Door panel Corner piece x 4...
-
Page 4: Tools Required
Components - Fittings Please check you have all the fittings listed below Note:The quantities below are the correct amount to complete the assembly .In some cases more fittings may be supplied than are required. Locking Nut x 8 Φ4 x 12mm Screw x 14 Locking Pin x 8 Φ3 x... - Page 5 Assembly Instructions Step 1 Assembling side panel and door panel Loosen straight hinge screw as shown to separate it into & Φ4 x 12mm screws to fix straight hinge onto door panel ． Screw locking pins into corner pieces as shown. Tips: not make the hinge in wrong way Insert wooden dowels...
- Page 6 Assembly Instructions Step 2 Assembling the unit Insert wooden dowels into top panel and bottom panel Carefully attach side panels to top panel and bottom panel, insert locking nuts into top and bottom panel,tighten locking nuts to secure. Step 3 Assembling back panel Use Φ3 x 12mm screw to fix...
- Page 7 After above assembly, please double check and make sure all screws are tigthened before us. NOTE:If you have damaged or missing components, call the Customer Helpline:08456 400800 Argos LTD,489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
-
Page 8: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit. -
Page 9: Safety Warning Information
SAFETY WARNING INFORMATION BS7449 : 1991 147/7584(D) Keep these instructions for future use: Catalogue Number: Manufacture date: Oct 22th, 2013 Retailer: Argos Retailer address: 489-499 Avebury Boulevard Saxon Gate West Central Milton Keynes WARNINGS Bucks, MK9 2NW *Do not place very hot or very cold items against or in...
