Industrial Electronic Devices
CHARACTERISTICS:
The HD67C58-B2 is a EnOcean / CANopen Slave Converter.
It allows the following characteristics:
Electrical isolation between Ethernet and Power Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 18...35V DC and 8...24V AC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67C58 software on your PC in order to perform the following:
Define the parameter of CANopen line;
Define the parameter of EnOcean line;
Define SDO Server information;
Define SDO Client information;
Define PDO information (RPDO/TPDO);
Export the EDS file for configuration of CANopen Master;
Update the device.
ADFweb.com S.r.l.
User Manual EnOcean / CANopen
Document code: MN67C58_ENG
Revision 1.000
Page 6 of 31
