INSTRUCTION AND SAFETY MANUAL FOR
T-SHAPED UNIVERSAL BASE SYSTEM FOR XTIRPA™
VEHICLES AND COUNTERBALANCED TRUCKS
UNIVERSAL RESCUE SYSTEM
IN-8012
™
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE
INNOVA Public Utility Products, Inc., 1040 BOUL. INDUSTRIEL, GRANBY, QUEBEC, CANADA
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com
P. 1
Numéro:
MU8012-002ANG Rev2 2016

Advertisement

loading
Need help?

Need help?

Do you have a question about the XTIRPA IN-8012 and is the answer not in the manual?

Questions and answers

Related Manuals for Innova XTIRPA IN-8012

Summary of Contents for Innova XTIRPA IN-8012

  • Page 1 UNIVERSAL RESCUE SYSTEM IN-8012 ™ TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE INNOVA Public Utility Products, Inc., 1040 BOUL. INDUSTRIEL, GRANBY, QUEBEC, CANADA Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com P. 1 Numéro: MU8012-002ANG Rev2 2016...
  • Page 2 WARNING The XTIRPA System is part of a personal protection equipment system for fall protection, work positioning, personnel handling, materials handling, or rescue, for use in confined spaces. The user must read, understand and follow the Manufacturer’s instructions for each component or part of the complete XTIRPA...
  • Page 3 DESCRIPTION & INTERPRETATION OF MARKING SYMBOLS This symbol is used to alert the user to a potential hazard. The safety of the worker is in jeopardy. It is imperative to follow the manufacturer’s recommendations. This symbol asks the user to read and understand the manual for this product before use. This symbol specifies that the system should be used by a single user.
  • Page 4 f) Wear all appropriate certified and recommended security equipment such as, but not limited to, hard hat, protective eyewear, leather gloves, protective clothing, work boots, harness in accordance with EN 361, flashlight and respiratory device if needed. WARNING: Equipment shall not be used past its capacity, or in any other applications for which the equipment was not designed.
  • Page 5 XTIRPA™ System is appropriate for your job, please contact the Manufacturer PSP INNOVA INC. WARNING: For safety r easons, make sur e when using the anti-drop system that you have enough space under the user, so as to avoid injury.

  • Page 6: System Requirements

    IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA System for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the maintenance and inspection log of this instruction and safety manual.
  • Page 7 g) A person who has not read the Instruction and safety manual, has not been trained in using the XTIRPA System and does not understand all operation and safety instructions, is not qualified to operate the XTIRPA System. An untrained user exposes himself and others to possible serious injury or death, for which the manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA...
  • Page 8 MAINTENANCE, SERVICING, STORAGE a) Before each use, the user must read and understand the Manufacturer’s Instruction and safety manual. Ensure that the markings are visible at all times. b) Before each use, carefully inspect the XTIRPA System and all components and parts thereof. Any defective parts or components could result in serious injury or death.

  • Page 9: Warranty

    WARRANTY The XTIRPA System offered by the Manufacturer, INNOVA Public Utility Products Inc., is warranted against manufacturing defects in workmanship and materials for a period of two (2) years from the date of shipment of the product, which warranty only covers the original purchaser of the XTIRPA System.
  • Page 10 XTIRPA SYSTEM DESCRIPTION WARNING The XTIRPA System is part of a personal fall arrest, work positioning, personnel handling, material handling or rescue system for use in confined spaces. The XTIRPA System is intended to act as a support structure or anchor for these uses. The user must read, understand and follow the manufacturer’s instructions for each component or part of the complete XTIRPA...
  • Page 11 Illustration 12: IN-8012 With A2305-12 Illustration 1: IN-2237 Illustration 7: A2305-12 Illustration 2: IN-2240 Illustration 8: A2305-65 Illustration 13: IN-8012 With A2305-65 Illustration 3: IN-2305 Illustration 9: A2305-16 Illustration 14: IN-8012 With A2305-16 Illustration 10: A2305-29 Illustration 4: A2305-40 Illustration 15: IN-8012 With A2305-29 Illustration 5: A2305-07 Illustration 11: IN-8012 With A2305-07 Illustration 6: A2305-25...
  • Page 12 OPERATION, ASSEMBLY AND USE XTIRPA SYSTEM TYPE A TYPE B TYPE E A2305-16 A2305-40 A2305-07 A2305-12 A2305-25 A2305-29 A2305-65 A2305-20 IN-8012 with A2305-07 IN-8012 with A2305-16 IN-8012 with A2305-12 A2305-55 IN-8012 with A2305-65 IN-8012 with A2305-29 P. 11 MU8012-002ANG Rev2 2016...
  • Page 13 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA System for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the maintenance and inspection log of this instruction and safety manual.
  • Page 14 OPERATION AND INSTALLATION OF THE T-SHAPED BASE SYSTEM WITH COUNTERBALANCED TRUCK (A2305-07) Make sure that all components and pieces are in perfect working condition and that everything is functioning correctly. IN-2305 IN-2237 A2305-07 A2305-40 IN-2240 A. Determine the placement of the truck. B.
  • Page 15 OPERATION AND INSTALLATION OF T-SHAPED BASE SYSTEM WITH BALLAST (A2305 -65) Make sure that all components and pieces are in perfect working condition and that everything is functioning correctly. IN-2305 IN-2237 A2305-65 A2305-40 IN-2240 A. Assemble the two parts of the tank platform. B.
  • Page 16 OPERATION AND INSTALLATION OF T-SHAPED BASE SYSTEM FOR BALLAST SUPPORT ASSEMBLY (A2305-65) (cont.) A. Inser t the fir st par t of the extension tube (A2305-40) into the adaptor on the platform and lock with the pin. B. Add the second par t of the extension tube (A2305-40) to the first and lock with the pin.
  • Page 17 OPERATION AND INSTALLATION OF T-SHAPED BASE WITH 1829MM (72") EXTENSION (A2305-16) FOR 63.5MM(2.5") T-SHAPED BASE COUPLING Make sure that all components and parts are in perfect working condition and that they are all functioning properly. IN-2305 IN-2237 A2305-20 A2305-25 A2305-55 IN-2240 A2305-16 Assemble the 1829mm (72") extension for...
  • Page 18 OPERATION AND INSTALLATION OF T-SHAPED UNIVERSAL BASE SYSTEM WITH 90- (A2305-29) DEGREE EXTENSION ADAPTOR Make sure that all components and parts are in perfect working condition and that they are all functioning properly. IN-2305 IN-2237 A2305-20 A2305-29 A2305-25 A2305-55 IN-2240 Assemble 90-degree extension (A2305-29) to T-shaped base union for (72") extension (A2305-25) and lock with pin.
  • Page 19 OPERATION AND TYPICAL INSTALLATION OF T-SHAPED BASE SYSTEM CONSISTING OF T-SHAPED UNIVERSAL BASE, MAST, AND DAVIT ARM . A. If necessar y, adjust base length using existing holes. B. Adjust to the desir ed length and lock the two sides to the universal T-shaped base with mast using locking pins.
  • Page 20 If you have questions regarding the use, maintenance or appropriateness of the XTIRPA system for your application, please contact the manufacturer PSP INNOVA INC. To install a second handling hoist or safety line, the following steps must be followed by using the A2237-06 handling hoist removable support.
  • Page 21 If you have any questions about the use or maintenance or whether the XTIRPA™ System is appropriate for your job, please contact the Manufacturer PSP INNOVA INC. WARNING: Any system must be immediately r emoved fr om cir culation if its safety is questioned, or if it was used to stop a fall.
  • Page 22 P. 21 MU8012-002ANG Rev2 2016...
  • Page 23 WARNING: When using a counter balanced tr uck, all the instr uctions r egar ding the weights r e- quired for specific applications must be followed. (see table below) WARNING: It should be noted that only those 22.7 kg (50 lbs) P2305-016N plates which were certified, ap- proved and recommended by the manufacturer can be used.
  • Page 24 KEEP THE FOLLOWING INSTRUCTIONAL AND SAFETY SIGNS CLEAN AND LEGIBLE AT ALL TIMES INSTRUCTION LABEL IN-2237 INSTRUCTION LABEL IN-2240 P. 23 MU8012-002ANG Rev2 2016...
  • Page 25 INSTRUCTION ABEL A2305-07 NSTRUCTION ABEL IN-2305 A2305-07 NSTRUCTION ABEL IN-2237 NSTRUCTION ABEL NSTRUCTION ABEL IN-2305 A2305-40 P. 24 MU8012-002ANG Rev2 2016...
  • Page 26 Calculation diagram P. 25 MU8012-002ANG Rev2 2016...
  • Page 27 This warranty applies only to the original purchaser and is the only one applicable to the Xtirpa System, and is in lieu of all other warranties, expressed or immplied. The purchaser has to complete and return to INNOVA Public Utility Products Inc., all information within thirty days of purchase. Otherwise limited warranty will be void, if the product is not registered.
  • Page 28 Manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA system waiving all claims, rights and recourses against Manufacturer and derived there from. INNOVA Public Utility Products Inc. Manufactured by 1040 boul. Industriel, Granby, Québec, Canada J2J 1A4 Tél: (450) 777-1240 Fax: (450) 372-9936...
