INSTRUCTION AND SAFETY MANUAL
XTIRPA™ Davit Arm System with Universal «T»
Adapter for Vehicle and Cart Counterweights for PPE
UNIVERSAL RESCUE SYSTEM
IN-8012
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE
INNOVA Public Utility Products Inc.
1040 Boulevard Industriel, Granby, Québec, Canada
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com
MU8012-(en-us)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Xtirpa IN-8012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innova Xtirpa IN-8012

Summary of Contents for Innova Xtirpa IN-8012

  • Page 1 Adapter for Vehicle and Cart Counterweights for PPE UNIVERSAL RESCUE SYSTEM IN-8012 TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE INNOVA Public Utility Products Inc. 1040 Boulevard Industriel, Granby, Québec, Canada Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com MU8012-(en-us)
  • Page 3 INTRODUCTION WARNING The XTIRPA system is part of a personal protection equipment system for fall protection, work positioning, personnel handling, materials handling, or rescue, for use in confined spaces. The user must read, understand and follow the manufacturer’s instructions for each com- ponent or part of the complete XTIRPA system.
  • Page 4 (Mast for fall protection and retrieval); IN-2313 (102mm (4’’) Mast for Davit-Arm IN-2237 1524mm (60’’) height); IN-2426 (Mast for davit arm 30’’ to 48’’ 500mm (19.7) high); IN-2237 (Extendable davit arm for fall protection and retrieval); IN-2305 (T-shaped universal base for 102mm (4”) mast);...
  • Page 5 SYMBOLS Indicates a dangerous situation which, if it not avoided, could lead to death or a dangerous injury. Indicates a dangerous situation which, if it not avoided, could lead to a minor or moderate injury. Indicated the safe working condition. Please read and understand this system’s operating manual before using it.
  • Page 6 Minimum and maximum service temperature. °C °F Maximum working load. Minimum breaking strength (MBS). Required tightening for bolt. Equipment maximum arrest force (MAF). The positioning pins must be installed before use. Minimum breaking strength (MBS) of 22.2 kN (5000 lbf). n°...
  • Page 7 APPLICATION The XTIRPA system, and its many components and parts (including davit arm, manhole guard, removable adapter, permanent adapter, integrated mast and side entry cart), are intended to be used as part of a personal protection equipment system for fall protection, work positioning, personnel handling, materials handling, or rescue, for use in confined spaces.
  • Page 8 RESTRICTIONS a) CAPACITY: The maximum working load for this product is 360 lbs (164 kg). According to (ANSI, OSHA, CSA). According to EC (EN 795 2012), use an EN 360 and/or EN 363 fall protection system or an EN 1496 recovery system. b) The manufacturer attests that anchoring devices have been tested accordingly to the cur- rent European standard (EN 795 2012 Type A, Type B and Type E) and, except otherwise stipulated, they are to be used by a single person using a shock absorber in accordance with...
  • Page 9 recommended for use in specialized work conditions such as those for which the XTIRPA system is intended to be used as per this instruction and safety manual. For the installation of lifeline cables and ropes on the certified 12kn anchor points of the davit arm, see section 6 paragraphs 3 and 5.
  • Page 10 XTIRPA system is appropriate for your job, please contact the manufacturer PSP INNOVA INC. WARNING: For safety reasons, make sure when using the anti-drop system that you have enough space under the user, so as to avoid injury. If a fall occurs, there should be enough space to avoid a collision with the ground or any obstacle.
  • Page 11 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this instruction and safety manual.
  • Page 12 f) Owners must also make sure that all users have successfully been trained in using the XTIRPA system, before allowing them to use the XTIRPA system, and at least annually thereafter. IMPORTANT: When used, the expandable coupling system for XTIRPA vehicles and counterbalanced trucks must be lifted using the adjustable supporting legs.
  • Page 13 WARNING: The safety of the user is in direct relation to the quality of maintenance and integrity of the equipment. Always use a bubble level to make sure the system is level. WARNING: When using a counterbalanced truck, all the instructions regarding the weights required for specific applications must be followed.
  • Page 14 MAINTENANCE, SERVICING, STORAGE a) Before each use, the user must read and understand the manufacturer’s Instruction and safety manual. Ensure that the markings are visible at all times. b) Before each use, carefully inspect the XTIRPA system and all components and parts thereof.

  • Page 15: Warranty

    WARRANTY The XTIRPA system offered by the manufacturer, INNOVA Public Utility Products Inc., is war- ranted against manufacturing defects in workmanship and materials for a period of two (2) years from the date of shipment of the product, which warranty only covers the original purchaser of the XTIRPA system.
  • Page 16 XTIRPA SYSTEM DESCRIPTION WARNING The XTIRPA system is part of a personal fall arrest, work positioning, personnel han- dling, material handling or rescue system for use in confined spaces. The XTIRPA sys- tem is intended to act as a support structure or anchor for these uses. The user must read, understand and follow the manufacturer’s instructions for each component or part of the complete XTIRPA system.
  • Page 17 102MM (4’’) MAST FOR DAVIT-ARM IN-2237 1524MM (60’’) HEIGHT: IN-2313 (see illustration 19) MAST FOR DAVIT ARM 30’’ TO 48’’ 500MM (19.7) HIGH: IN-2426 (see illustration 20) Illustration 1: Illustration 4: Illustration 8: IN-2237 A2305-40 A2305-65 Illustration 9: Illustration 2: Illustration 5: A2305-16 IN-2240...
  • Page 18 Illustration 16: Illustration 20: Illustration 12: A2305-20 IN-2426 IN-8012 with A2305-12 Illustration 17: A2305-55 Illustration 13: IN-8012 with A2305-65 Illustration 18: IN-2517 Illustration 14: IN-8012 with A2305-16 Illustration 19: IN-2313 Illustration 15: IN-8012 with A2305-29 MU8012-(en-us)
  • Page 19 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this instruction and safety manual.
  • Page 20 Remove the pins from the level adjustment screws and rotate them to a vertical position. Tighten the level adjustment screws. Use a bubble level and make sure that the bubble is in the center of the indicator. CAUTION: When used, the counterbalanced truck must be lifted so that the wheels do not come into contact with the ground, only the level adjustment screws.
  • Page 21 Make sure that the locking handle is firmly screwed in place. Level the system. OPERATION AND INSTALLATION OF T-SHAPED BASE SYSTEM WITH BALLAST (A2305-65) Make sure that all components and pieces are in perfect working condition and that everything is functioning correctly. A.
  • Page 22 If necessary, adjust the angle +/- 5 degrees. Lock angle with pin. OPERATION AND INSTALLATION OF T-SHAPED BASE SYSTEM FOR BALLAST SUP- PORT ASSEMBLY (A2305-65) (cont.) Insert the first part of the extension tube (A2305-40) into the adaptor on the platform and lock with the pin. Add the second part of the extension tube (A2305-40) to the first and lock with the pin.
  • Page 23 Make sure that the locking handle is screwed firmly in place. Level the system. OPERATION AND INSTALLATION OF T-SHAPED BASE WITH ANCHORING ADAPTOR FOR T-SHAPED UNIVERSAL BASE (A2305-12) Make sure that all components and parts are in perfect working condition and that they are all functioning properly.
  • Page 24 After adjusting the height, lock with the pin. OPERATION AND INSTALLATION OF T-SHAPED BASE WITH 1829MM (72”) EXTENSION FOR 63.5MM(2.5”) T-SHAPED BASE COUPLING (A2305-16) Make sure that all components and parts are in perfect working condition and that they are all functioning properly. Assemble the 1829mm (72”) extension for 63.5mm (2.5”) T-shaped base coupling (A2305- 16) to T-shaped base union with 1829mm (72”)
  • Page 25 Insert 1829mm (72”) extension for 63.5mm (2.5”) T-shaped base coupling (A2305- 16) into previously installed A2305-55 and lock with pin. Insert base union for 1829mm (72”) extension (A2305-25) into T-shaped universal base. Lock tube with pin. Make sure that the locking handle is frimly screwed in place. Level the system.
  • Page 26 Insert 90-degree extension (A2305-29) into previ- ously installed A2305-20 and lock with pin. Insert 63.5-51mm (2.5-2”) coupling reducer for T-shaped base extension (A2305-20) into vehicle hitch and lock with coupling pin. Installation of A2305-55 (if necessary). Insert 63.5- 51mm coupling reducer (2.5-2”) for T-shaped base extension (A2305-20) into vehicle hitch and lock with coupling pin.
  • Page 27 Make sure the locking handle is screwed firmly into place. Level the system. OPERATION AND TYPICAL INSTALLATION OF T-SHAPED BASE SYSTEM CONSISTING OF T-SHAPED UNIVERSAL BASE, MAST, AND DAVIT ARM If necessary, adjust base length using existing holes. Adjust to the desired length and lock the two sides to the univer- sal T-shaped base with mast using locking pins.
  • Page 28 Insert mast into the receptacle in the universal T-shaped base. Lock with pin. Install davit arm receptacle on mast. Lock with pin. Install lifeline or winch on the davit arm bracket designed for this type of equipment. Use provided locking pin on the lifeline or winch bracket and lock everything with it.
  • Page 29 XTIRPA system for your appli- cation, please contact the manufacturer PSP INNOVA INC. WARNING: Only adaptors and brackets that are approved, certified and recommended by the manufacturer are to be used with the XTIRPA system.
  • Page 30 WARNING: For all fall protection devices, it is essential, for safety purposes, that anchor- ing device is always positioned correctly and that the task to be performed should be done in a manner to reduce risk of fall and height of fall. The anchoring point and fall protection device must be placed directly over the user’s position.
  • Page 31 KEEP THE FOLLOWING INSTRUCTIONAL AND SAFETY SIGNS CLEAN AND LEGIBLE AT ALL TIMES SERIAL NUMBER LABEL Product serial number Product number Manufacturing date Manufacturing batch number MU8012-(en-us)
  • Page 32 MU8012-(en-us)
  • Page 33 CALCULATION DIAGRAM Anchor point Elastic deformation Length of the lanyard carabiner Extended length of the absorber Distance between harness buckle and feet = 5’ (1.5 m) Minimum safe distance = 3.3’ (1 m) MU8012-(en-us)
  • Page 34 MU8012-(en-us)
  • Page 35 MU8012-(en-us)
  • Page 36 NOTES MU8012-(en-us)
  • Page 37 NOTES MU8012-(en-us)
  • Page 38 NOTES MU8012-(en-us)
  • Page 40 Head Office and Manufacturing Plant Innova Public Utility Productions Inc. 1040, Boulevard Industriel Granby, Qc, Canada J2J 1A4 Phone: 450.777.1240 Toll free: 1.800.461.1937 XTIRPA is a registered trademark of INNOVA Public Utility Productions Inc. www.xtirpa.com used under license in Canada MU8012-(en-us)_rev05.03...
