INSTRUCTION AND SAFETY MANUAL
XTIRPA DAVIT ARM AND MAST SYSTEM FOR PPE
UNIVERSAL RESCUE SYSTEM
IN-8016
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE
INNOVA Public Utility Products Inc.
1040 Boulevard Industriel, Granby, Québec, Canada
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com
MU8016-012ENG rev02
Advertisement
Related Manuals for Innova XTIRPA IN-8016
Summary of Contents for Innova XTIRPA IN-8016
- Page 1 XTIRPA DAVIT ARM AND MAST SYSTEM FOR PPE UNIVERSAL RESCUE SYSTEM IN-8016 TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE INNOVA Public Utility Products Inc. 1040 Boulevard Industriel, Granby, Québec, Canada Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com MU8016-012ENG rev02...
- Page 3 INTRODUCTION WARNING The XTIRPA system is part of a personal protection equipment system for fall protection, work positioning, or rescue, for use in confined spaces. The user must read, understand and follow the manufacturer’s instructions for each com- ponent or part of the complete XTIRPA system. These instructions must be provided to the user of the XTIRPA system.
- Page 4 initial production and certification control phase. DESCRIPTION & INTERPRETATION OF MARKING SYMBOLS This symbol is used to alert the user to a potential hazard. The safety of the worker is in jeopardy. It is imperative to follow the manufacturer’s recommendations. This symbol asks the user to read and understand the manual for this product before use.
- Page 5 RESTRICTIONS a) CAPACITY: The maximum working load (CMT) of this product is 360lbs (164kg). According to EN 795: 2012 and TS16415: 2013, use an EN-360 fall protection system and / or EN-363 or EN-1496 recovery system. b) The manufacturer certifies that the anchoring devices have been tested in accordance with this European standard (EN 795: 2012 Type A and TS16415: 2013) and that, unless indicat- ed otherwise, they are suitable for use by a single person, by anchor point, with an energy absorber in accordance with EN 355.
- Page 6 h) Use only a certified full body harness in accordance with EN 361 and lifeline cables and ropes for any user of the XTIRPA system, with appropriate specifications designed and recommended for use in specialized work conditions such as those for which the XTIRPA system is intended to be used as per this instruction and safety manual.
- Page 7 If you have any questions about use or maintenance or whether the XTIRPA system is appropriate for your job, please contact the manufacturer PSP INNOVA INC. WARNING: For safety reasons, make sure when using the anti-drop system that you have enough space under the user, so as to avoid injury.
- Page 8 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this Instruction and safety manual.
- Page 9 h) Refer to and follow all EN standards or other local standards and regulations. Observe all the requirements of your local regulations for your applications. See other important operation instruction and safety information contained hereafter in this instruction and safety manual. It is imperative to supply all information in sufficient quantity to assure that different equip- ment articles are compatible when assembled as a system.
- Page 10 MAINTENANCE, SERVICING, STORAGE a) Before each use, the user must read and understand the manufacturer’s Instruction and safety manual. Ensure that the markings are visible at all times. b) Before each use, carefully inspect the XTIRPA system and all components and parts there- of.
-
Page 11: Garantie
GARANTIE The XTIRPA system offered by the manufacturer, INNOVA Public Utility Products Inc., is war- ranted against manufacturing defects in workmanship and materials for a period of two (2) years from the date of shipment of the product, which warranty only covers the original purchaser of the XTIRPA system. - Page 12 XTIRPA SYSTEM DESCRIPTION WARNING The XTIRPA system is part of a personal fall arrest, work positioning, personnel handling, material handling or rescue system for use in confined spaces. The XTIRPA system is intended to act as a support structure or anchor for these uses. The user must read, understand and follow the manufacturer’s instructions for each component or part of the complete XTIRPA system.
- Page 13 Illustration 4: IN- Illustration 7: Illustration 1: IN- 2105 A2395-07 2395 Illustration 8: IN- Illustration 5: 8016 Illustration 2: IN- A2395-06 2005 Illustration 3: IN- Illustration 6: 2013 A2395-12 MU8016-012ENG rev02...
- Page 14 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this instruction and safety manual.
- Page 15 Installation with mast extension. Insert the mast extension into the certified, approved and recommended anchor point. Ensure that the locking pin attached to the adapter is in place. Insert the mast on the extension. Make sure that the locking pin, attached to the extension, is in place.
- Page 16 WARNING: It should be noted that only plates, support and adaptors that have been cer- tified, approved and recommended by the manufacturer can be used. WARNING: For the fall arrest systems, it is essential for safety that the anchoring device or the anchor point is always correctly positioned and that effort is made so as to reduce the risk of falls and the height of fall.
- Page 17 WARNING: The XTIRPA system must be used only with adapters, anchors, connectors (EN 362), pulleys, other components, parts and subsystems certified, approved and rec- ommended by the manufacturer. Substitutions or replacements made with non-approved adapters, anchors, connectors, other components, parts or subsystems may be incom- patible, and may jeopardize the safety and reliability of the complete XTIRPA system and may result in serious injury or death, for which manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA system waiving all claims,...
-
Page 18: Serial Number Label
Notified body’s no. Accredited standard’s no. 0082 2 MAX EN 795:2012 Products manufactured by: Innova Public Utility Products inc. 1040 boul. Industriel Type B Granby, QC, Canada J2J 1A4 www.xtirpa.com S2395-102 revB Made in Canada S2324-004 revB... - Page 19 CALCULATION DIAGRAM Ground Clearance: Length of the lanyard carabiner Extended length of the absorber Distance between harness buckle and feet = 4.9’ (1.5 m) Minimum safe distance = 3.3’ (1 m) Pay attention to the distance to the ground! MU8016-012ENG rev02...
- Page 20 MU8016-012ENG rev02...
- Page 21 MU8016-012ENG rev02...
- Page 22 NOTES MU8016-012ENG rev02...
- Page 24 Head Office and Manufacturing Plant Innova Public Utility Productions Inc. 1040, Boulevard Industriel Canada, Qc, Canada J2J 1A4 Phone: 450.777.1240 Toll free: 1.800.461.1937 Xtirpa is a registered trademark of Innova Public Utility Productions Inc. used under www.xtirpa.com license in Canada MU8016-012ENG rev02...
