INSTRUCTION AND SAFETY MANUAL
XTIRPA 24'' (610mm) Mast & Davit Arm system with
Shoring system
UNIVERSAL RESCUE SYSTEM
IN-8018
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE
INNOVA Public Utility Products Inc.
1040 Boulevard Industriel, Granby, Québec, Canada
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com
MU8018-012ENG rev03

Advertisement

loading
Need help?

Need help?

Do you have a question about the Xtirpa IN-8018 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innova Xtirpa IN-8018

Summary of Contents for Innova Xtirpa IN-8018

  • Page 1 XTIRPA 24’’ (610mm) Mast & Davit Arm system with Shoring system UNIVERSAL RESCUE SYSTEM IN-8018 TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE INNOVA Public Utility Products Inc. 1040 Boulevard Industriel, Granby, Québec, Canada Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com MU8018-012ENG rev03...
  • Page 3 INTRODUCTION WARNING The XTIRPA system is part of a personal protection equipment system for fall protection, work positioning, or rescue, for use in confined spaces. The user must read, understand and follow the manufacturer’s instructions for each com- ponent or part of the complete XTIRPA system. These instructions must be provided to the user of the XTIRPA system.
  • Page 4 DESCRIPTION & INTERPRETATION OF MARKING SYMBOLS This symbol is used to alert the user to a potential hazard. The safety of the worker is in jeopardy. It is imperative to follow the manufacturer’s recommendations. This symbol asks the user to read and understand the manual for this product before use.
  • Page 5 RESTRICTIONS a) CAPACITY: The maximum working load (CMT) for this product is 360lbs (164kg). According to CE (EN 795: 2012 and TS16415: 2013), use a system EN-360 and / or EN-363 fall arrester or EN-1496 recovery system. b) The manufacturer certifies that the anchoring devices have been tested in accordance with this European standard (EN 795: 2012 Type B and TS16415: 2013) and that, unless other- wise indicated, they are suitable for use by a single person, by anchor point, with an energy absorber in accordance with EN 355.
  • Page 6 IMPORTANT: During installation of the system, it is important to ensure stability through- out. Plan your work program before starting. Have the required equipment, procedures and peo- ple, which must be qualified and trained on the XTIRPA system and who must have read and understood this instruction and safety manual before using the XTIRPA system, available to do the job.
  • Page 7 If you have any questions about use or maintenance or whether the XTIRPA system is appropriate for your job, please contact the manufacturer PSP INNOVA INC. WARNING: For safety reasons, make sure when using the anti-drop system that you have enough space under the user, so as to avoid injury.
  • Page 8 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this instruction and safety manual.
  • Page 9 possible serious injury or death, for which the manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA system waiving all claims, rights and recourses against the manufacturer derived therefrom. h) Refer to and follow all EN standards or other local standards and regulations. Observe all the requirements of your local regulations for your applications.
  • Page 10 MAINTENANCE, SERVICING, STORAGE a) Before each use, the user must read and understand the manufacturer’s Instruction and safety manual. Ensure that the markings are visible at all times. Before each use, carefully inspect the XTIRPA system and all components and parts there- of.

  • Page 11: Garantie

    GARANTIE The XTIRPA system offered by the manufacturer, INNOVA Public Utility Products Inc., is war- ranted against manufacturing defects in workmanship and materials for a period of two (2) years from the date of shipment of the product, which warranty only covers the original purchaser of the XTIRPA system.
  • Page 12 XTIRPA SYSTEM DESCRIPTION WARNING The XTIRPA system is part of a personal fall arrest, work positioning, personnel handling, material handling or rescue system for use in confined spaces. The XTIRPA system is intended to act as a support structure or anchor for these uses. The user must read, understand and follow the manufacturer’s instructions for each component or part of the complete XTIRPA system.
  • Page 13 Illustration 4 - Illustration 1 - IN- A2395-07 8018 Illustration 2 - IN- Illustration 5 2482 Illustration 3 - Illustration 6 IN-2483 MU8018-012ENG rev03...
  • Page 14 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this instruction and safety manual.
  • Page 15 XTIRPA system on a soft surface, including, but not limited to, sand, grass, gravel and rocks. If you have any questions about the use or maintenance or whether the XTIRPA system is appropriate for your job, please contact the manufacturer PSP INNOVA INC. OPERATION AND INSTALLATION OF THE SYSTEM WITH ADJUSTABLE AND NON-AD-...
  • Page 16 XTIRPA system on a soft surface, including, but not limited to, sand, grass, gravel and rocks. If you have any questions about the use or maintenance or whether the XTIRPA system is appropriate for your job, please contact the manufacturer PSP INNOVA INC. MU8018-012ENG rev03...
  • Page 17 OPERATION AND INSTALLATION OF THE WINCH OR LIFELINE ON BASE OF DAVIT ARM DESIGNED FOR THIS TYPE OF EQUIPMENT Install the winch or lifeline on the base of the davit arm designed for use with this type of equipment. Use a locking pin which was provided with the winch or lifeline bracket and lock it.
  • Page 18 IMPORTANT: If necessary, use a manhole guard to secure the working area and to pre- vent falls. IMPORTANT: A fall protection harness in accordance with EN 361 is the only body support device allowed to be used for fall protection. IMPORTANT: The fall protection harness in accordance with EN 361 must be attached to the winch’s cable or rope by the anchoring point of the EN 361-compliant harness.

  • Page 19: Serial Number Label

    KEEP THE FOLLOWING INSTRUCTIONAL AND SAFETY SIGNS CLEAN AND LE- GIBLE AT ALL TIMES SERIAL NUMBER LABEL Product serial number Product number Manufacturing date Manufacturing batch number CE ACCREDITATION LABEL Accredited standard’s no. EN 795:2012 Type A S2337-003 revD Product standard CE ACCREDITATION LABEL Notified body’s no.
  • Page 20 MU8018-012ENG rev03...
  • Page 21 CALCULATION DIAGRAM Ground Clearance: Length of the lanyard carabiner Extended length of the absorber Distance between harness buckle and feet = 4.9’ (1.5 m) Minimum safe distance = 3.3’ (1 m) Pay attention to the distance to the ground! MU8018-012ENG rev03...
  • Page 22 MU8018-012ENG rev03...
  • Page 23 MU8018-012ENG rev03...
  • Page 24 NOTES MU8018-012ENG rev03...
  • Page 25 NOTES MU8018-012ENG rev03...
  • Page 26 NOTES MU8018-012ENG rev03...
  • Page 28 Head Office and Manufacturing Plant Innova Public Utility Productions Inc. 1040, Boulevard Industriel Canada, Qc, Canada J2J 1A4 Phone: 450.777.1240 Toll free: 1.800.461.1937 Xtirpa is a registered trademark of Innova Public Utility Productions Inc. used under www.xtirpa.com license in Canada MU8018-012ENG rev03...
