INSTRUCTION AND SAFETY MANUAL XTIRPA 762mm-
1219mm (30" to 48") Extendable Fall Protection & Re-
trieval Davit Arm for PPE
UNIVERSAL RESCUE system
IN-8005
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE
INNOVA Public Utility Products Inc.
1040 Boulevard Industriel, Granby, Québec, Canada
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com
MU8005-012ENG rev04

Advertisement

loading
Need help?

Need help?

Do you have a question about the XTIRPA IN-8005 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innova XTIRPA IN-8005

Summary of Contents for Innova XTIRPA IN-8005

  • Page 1 Davit Arm for PPE UNIVERSAL RESCUE system IN-8005 TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE INNOVA Public Utility Products Inc. 1040 Boulevard Industriel, Granby, Québec, Canada Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com MU8005-012ENG rev04...
  • Page 3 INTRODUCTION WARNING The XTIRPA system is part of a personal protection equipment system for fall protection, work positioning, or rescue, for use in confined spaces. The user must read, understand and follow the manufacturer’s instructions for each com- ponent or part of the complete XTIRPA system. These instructions must be provided to the user of the XTIRPA system.
  • Page 4 DESCRIPTION & INTERPRETATION OF MARKING SYMBOLS This symbol is used to alert the user to a potential hazard. The safety of the worker is in jeopardy. It is imperative to follow the manufacturer’s recommendations. This symbol asks the user to read and understand the manual for this product before use.
  • Page 5 RESTRICTIONS a) CAPACITY: The maximum working load (CMT) of this product is 360lbs (164kg). According to EN 795: 2012 and TS16415: 2013, use an EN-360 and / or EN-363 fall protection system or EN-1496 recovery system. b) The manufacturer certifies that the anchoring devices have been tested in accordance with this European standard (EN 795: 2012 Type A and TS16415: 2013) and that, unless other- wise indicated, they are suitable for use by a single person, by anchor point, with an energy absorber in accordance with EN 355.
  • Page 6 h) Use only a full body harness conforming to EN 361 as well as certified lifeline cables and ropes, for any user of the XTIRPA system, having the appropriate specifications and de- signed and recommended for use in conditions of specialized work such as that for which the XTIRPA system was designed, as indicated in this Instruction and Safety Manual.
  • Page 7 If you have any questions about use or maintenance or whether the XTIRPA system is appropriate for your job, please contact the manufacturer PSP INNOVA INC. WARNING: For safety reasons, make sure when using the anti-drop system that you have enough space under the user, so as to avoid injury.
  • Page 8 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this instruction and safety manual.
  • Page 9 g) A person who has not read the instruction and safety manual, been trained in using the XTIRPA system and does not understand all operation and safety instructions, is not qual- ified to operate the XTIRPA system. An untrained user exposes himself and others to pos- sible serious injury or death, for which manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA system waiving all claims, rights and recourses against manufacturer derived there from.
  • Page 10 MAINTENANCE, SERVICING, STORAGE a) Before each use, the user must read and understand the manufacturer’s instruction and safety manual. Ensure that the markings are visible at all times. b) Before each use, carefully inspect the XTIRPA system and all components and parts there- of.

  • Page 11: Warranty

    WARRANTY The XTIRPA system offered by the manufacturer, INNOVA Public Utility Products Inc., is war- ranted against manufacturing defects in workmanship and materials for a period of two (2) years from the date of shipment of the product, which warranty only covers the original purchaser of the XTIRPA system.
  • Page 12 XTIRPA SYSTEM DESCRIPTION WARNING The XTIRPA system is part of a personal fall arrest, work positioning, personnel riding, material handling or rescue system for use in confined spaces. The XTIRPA system is intended to act as a support structure or anchorage for these uses. The user must read, understand and follow manufacturer’s instructions for each component or part of the com- plete XTIRPA system.
  • Page 13 Illustration 1: IN-2237 Illustration 2: IN-2240 Illustration 3: IN-2313 Illustration 4: IN-2426 Illustration 5: Illustration 6: Illustration 7: Illustration 8: A2237-06 IN-2238 IN-2253 IN-2254 Illustration 9: Illustration Illustration 11: Illustration 12: IN-2302 A2237-17 IN-2304 IN-2303 Illustration 13: Illustration 14: Illustration 15: Illustration 16: IN-2451 IN-2452...
  • Page 14 IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the manufacturer INNOVA Public Utility Products Inc. IMPORTANT: Record the product identification information from the ID label in the main- tenance and inspection log of this instruction and safety manual.
  • Page 15 Install the receptacle of the davit arm on the mast. Install the lifeline cable or rope or winch on mounting bracket made to accept the hoisting device and safely lock with pin at- tached to the SRL or Winch bracket. A second lifeline or winch can be installed on the jib.
  • Page 16 4-5-6 on installation of material/positioning winch. If you have any questions concerning the use, maintenance or appropriate characteristics of the XTIRPA for your application, please contact the manufacturer INNOVA Public Utility Products Inc. WARNING: Only adaptors and brackets approved, certified and recommended by the man- ufacturer are to be used with the XTIRPA system.
  • Page 17 WARNING: With the use of a fall protection device, it is essential for safety purposes, to verify the free space required under user on work site before each use to avoid and prevent fall, in case of collision with ground or any other obstacle that could be in the path of the fall.
  • Page 18 KEEP THE FOLLOWING INSTRUCTIONAL AND SAFETY SIGNS CLEAN AND LEGIBLE AT ALL TIMES. MU8005-012ENG rev04...

  • Page 19: Serial Number Label

    ÉTIQUETTE ACCRÉDITATION CE No. de la norme accréditée EN 795:2012 Type A S2337-003 revD Norme du produit SERIAL NUMBER LABEL CE ACCREDITATION LABEL Product serial number Notified body’s no. Product number Accredited standard’s no. 0082 EN 795:2012 Type B S2324-004 revB Product standard Manufacturing date European compliance...
  • Page 20 CALCULATION DIAGRAM Ground Clearance: Length of the lanyard carabiner Extended length of the absorber Distance between harness buckle and feet = 4.9’ (1.5 m) Minimum safe distance = 3.3’ (1 m) Pay attention to the distance to the ground! MU8005-012ENG rev04...
  • Page 21 MU8005-012ENG rev04...
  • Page 22 MU8005-012ENG rev04...
  • Page 24 Head Office and Manufacturing Plant Innova Public Utility Productions Inc. 1040, Boulevard Industriel Canada, Qc, Canada J2J 1A4 Phone: 450.777.1240 Toll free: 1.800.461.1937 Xtirpa is a registered trademark of Innova Public Utility Productions Inc. used under www.xtirpa.com license in Canada MU8005-012ENG rev04...
