ASSEMBLY INSTRUCTION
Item#:SS460-P3/SS460-P2/SS460-PWR- Recliner
How to assemble the recliner back
1.When assembling your recliner, please lay down the recliner carefully on soft surface.
Place the bracket into sleeve and press top of back down firmly to lock into place.
2.To remove the back, use screwdrive to rise up the sleeve on both side
then lift the back from the base
How to use memory button
1. Memory function: When the sofa being adjusted to a comfortable position you fell, press the
memory button for 3s till the 4-button blue lights (as picture 2) flashing for 3 times. Then the
comfortable position is recorded. Next time, by pushing the memory button one time , the sofa
will go to the comfortable position that you set before ,if you want to stop the memory function
right now, just press any buttons on the product. We set the memory function which only can
open but can not close the seat and head motor to make sure safety. The memory will not work
if any motor stop position is over the position which recorded before .
2 HOME function: by pushing and hold the HOME button, the sofa will be all closed, if you
release the HOME button, the sofa will stop close.
3. USB charging port: The output Voltage on the USB port is 5V and the output current is 1A.
PLEASE DO NOT USE A MULTI-BOARD OR MORE THAN TWO USB DEVICES AT ONE
TIME, OR DAMAGE COULD OCCUR.
Advertisement
Table of Contents
Related Manuals for Hooker Furniture SS460-CW-188
Summary of Contents for Hooker Furniture SS460-CW-188
- Page 1 ASSEMBLY INSTRUCTION Item#:SS460-P3/SS460-P2/SS460-PWR- Recliner How to assemble the recliner back 1.When assembling your recliner, please lay down the recliner carefully on soft surface. Place the bracket into sleeve and press top of back down firmly to lock into place. 2.To remove the back, use screwdrive to rise up the sleeve on both side then lift the back from the base How to use memory button 1.
- Page 2 power cord connection extention cable 1 Take out A and B from the part box, Connect the Transformer(A), AC power cable(B) to the extention cable ( C ) as abover. 2 Area D was connected by factory, if it get loose, please reconnect as shown.
Need help?
Do you have a question about the SS460-CW-188 and is the answer not in the manual?
Questions and answers
SS460-p3-188 ;The foot rest is stuck up. I think I need to replace the control button on the side. It is the right side of the couch.(when sitting in the couch, it is the left side). Which replacement do I use? MLSK46-C(R) or MLSK46-C(L)
