PXM PxAqua 3 SH Manual

Hide thumbs Also See for PxAqua 3 SH:

Advertisement

Table of Contents

PX 229
PxAqua 3
SH/SP
Manual
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PxAqua 3 SH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PXM PxAqua 3 SH

Summary of Contents for PXM PxAqua 3 SH

  • Page 1 PX 229 PxAqua 3 SH/SP Manual...

  • Page 2: Table Of Contents

    Manufacturer reserves the right to make modifications in order to improve device operation. Rev 1.5 tel.: +48 12 626 46 92 PXM Marek Żupnik limited partnership fax: +48 12 626 46 94 ul. Przemysłowa 12 E-mail: info@pxm.pl 30-701 Kraków, Poland...

  • Page 3: General Description

    1. General description Underwater lamp LED LAMP PX 229 with an adjustable handle has built-in 3 LEDs. The PX 229 lamp is designed for both underwater and open air installations, which require high brightness lighting. In underwater sollutions the lamp can be powered with 700mA current and reach 3x3Watt of power (in open air sollutions it has to work with 350mA power supply and reach 3x1Watt).
  • Page 4 Keep ESD protection because the module and installed LEDs may be damaged by static electricity generated in equipment, people, tools and other insulators or semiconductors. While working at an ambient temperature of 25°C housing unit can heat up to 65°C. Because of the danger of burns, avoid direct contact with the casing. In case of improper usage of the product it may cause a risk of serious injury or death because of the threat of fire.

  • Page 5: Information About The Lamp Version

    3. Information about the lamp version The PX 229 lamp is available in several versions differing in angle of used lenses. Below is a description of the PX229 models designations and their explanation. PX 229 - XX - YYY - ZZ XX-lens angle.
  • Page 6 4. Description 3 LEDs 2 screws with washer fastening the holder and casing together (allows you to adjust the angle the lamp in the vertical plane) Handle 3 holes for fastening screws...

  • Page 7: Connections Scheme

    5. Connections scheme a) RGB lamp connection The RGB version of lamp is connected via 6-strand cable, e.g. shown in the figures below. RED + (red) RED - ( red with black stripe GREEN - (green with black stripe GREEN + (green) BLUE - ( blue with black stripe...
  • Page 8 350 mA power supply 700 mA power supply Power Quantity of Driver supply powered lamps Power Quantity of Driver supply powered lamps PY417-12V PX305 PY415-12V PY415-24V PX307 PY417-12V PY421-24V PX308 PY415-24V PY415-12V PY421-48V 7-12 PX184 PY421-24V PY417-12V PY404-48V 7-12 PX215 PY415-24V PY421-48V 7-12...

  • Page 9: Dimensions

    6. Dimensions Version with handle (PX229-SH) 48,5 mm Version for flush mount (PX229-SP) 5 mm 120 mm sealing O-ring stainless-steel tube wall thickness: 2mm 7. Technical Data Number of LEDs: Casing Material: Stainless steel Casing IP class: IP 68 Max. power consumption: ~ 3,3 W (350 mA, full brightness, white color) ~ 8,1 W (700 mA, full brightness, white color) Dimensions:...

  • Page 10: Declaration Of Conformity

    30-701 Kraków, Poland fax: +48 12 626 46 94 DECLARATION OF CONFORMITY according to guide lines of 2006/95/EC Name of producer: PXM Marek Żupnik sp. k. Address of producer: ul. Przemysłowa 12 30-701 Kraków, Poland declares that the product: Name of product:...

This manual is also suitable for:

Pxaqua 3 sp
