Summary of Contents for PXM PX229-H Series
- Page 1 PX229-H PX229-P PxAqua 3 SH PxAqua 3 SP User manual...
-
Page 2: Table Of Contents
4 Connection scheme...................7 5 Dimensions....................8 6 Method of mounting..................9 7 Technical data..................10 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.2-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description The PxAqua 3 SH / SP LED lamp is designed for underwater lighting. In addition, it can be used to illuminate interiors and architectural details. The lamp uses three high-performance LEDs Osram Oslon , which ® ensures its excellent lighting parameters. It can be equipped with optics with different beam angles (10 °, 25 °... -
Page 4: Safety Conditions
Safety conditions Before installing, connecting and using the lamp you have to absolutely read this document. The following symbols are used to underline important information on security conditions on the product and in this manual. Danger! Warning! Warning! Warning! Warning! Risk of loss of life Fire hazard. - Page 5 During its installation and use PX 229 the following rules must be strictly observed: 1. Installation should be performed by a person holding the appropriate qualifications, according to the instruction manual. 2. Lamp may only be connected to stabilized voltage with current-carrying capacity compatible with technical data.
-
Page 6: Information On Version
Information on version The PX229 lamp is available in several versions that differ in the angle of the lenses used and the color of the LEDs. Below there is a description of designation of the PX229 models and their explanation: PX229 –... -
Page 7: Connection Scheme
Connection scheme a) connecting monochrome lamps to the driver Current driver + (red) – (black) power supply 12 - 48V DC V- V+ b) connecting a monochrome lamp to the power supply current power supply 350 - 700mA V- V+... -
Page 8: Dimensions
c) connecting RGB lamps in series to the driver LED lamp Current driver LED lamp R– (red/black) power supply 12 - 48V DC R+ (red) V- V+ G– (green/black) G+ (green) LED lamp G– (blue/black) G+ (blue) Dimensions 48,5 Version for flush mounting mounting O-ring stainless steel tube the wall thickness is 2mm... -
Page 9: Method Of Mounting
Method of mounting The lamp is attached to the holder with two M3 Allen screws and can be rotated vertically. The handle, on the other hand, is attached to the ground with an M5 screw, which in turn allows for rotation in the horizontal plane. -
Page 10: Technical Data
Technical data PX229-H – version with a handle type PX229-P – overrun version (for installation in a pipe) for RGB version: 3 x 350mA or 3 x 700mA underwater version power supply for monochrome version: 1 x 350mA or 1 x 700mA underwater version IP rate IP68... - Page 11 Podłęże, 31.03.2021 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: PxAqua 3 SH PxAqua 3 SP Product code: PX229-H PX229-P meets the requirements of the following standards, as well as harmonised...
