- Page 1 PX314 Dimmer 24 x 3600W MANUAL...
-
Page 2: Table Of Contents
8. Technical data..................Declaration of conformity................ Manufacturer reserves the right to make modifications in order to improve device operation. tel.: 12 626 46 92 PXM Marek Żupnik spółka komandytowa fax: 12 626 46 94 ul. Przemysłowa 12 Rev. 1.0 e-mail: info@pxm.pl 30-701 Kraków... -
Page 3: General Description
1. GENERAL DESCRIPTION PX314 AC+ Dimmer 24x 3600 W can be powered by three phases, and has an integrated system fully protecting against the effects of reverse phases connection. The device allows you to control 24 independent channels with a power of 3.6 kW each. The... -
Page 4: Front Panel / Interface
The displays also allows you to set the parameters of the dimmer. You may be asked to give a password to enter the settings menu. programming Px314 DIMMER NR: 1 knob DMX 1: DMX 2:... -
Page 5: Operation
PREV keys or the knob. selection activation 4. OPERATION After starting the device, the display shows the start screen, including: name and number Px314 DIMMER NR: 1 information whether the of the dimmer device requires you to give DMX 1: DMX 2:... -
Page 6: Summary Screen
4.1 Summary screen Pressing the [INFO] key takes you to the summary screen. This screen includes the following information: error notification key (if any) phase voltage INFO key to return to the total current main screen PHASE 1: PHASE 2: PHASE 3: CURRENT: TEMPERATURE 1:... -
Page 7: Programming
Pressing one of the channel keys takes you to the corresponding channel summary screen. This screen displays the following information: v a l u e g a i n e d b y merging inputs (0- CHANNEL 1 255) value on the output MERGED VALUE: merge mode depending on the output... - Page 8 If you select [RANGE], the following fields will be available on the screen: reduction of output p o w e r ( r a n g e RANGE FROM range of channels for 0-100%) POWER 100 % which the parameters maximum current on MAX CURRENT 16 A...
-
Page 9: Program
5.3 Program In the [PROGRAMMING] menu, you can program 128 scenes and a program that can be activated in the absence of DMX signal. Scene is a static adjustment of the value at the output channels. Program is a set of successive scenes. The screen shows the following keys: EDIT –... -
Page 10: Scene Copy
5.3.2 Scene copying Scene copying screen contains 2 fields: [FROM] and [TO] which allow you to specify the source scene and the target scene between which the values are to be copied. 5.3.3 Scene capture Scene capture option allows you to save current values on the output channels to the selected scene. -
Page 11: No Signal
5.3.6 No signal By using the [NO DMX SIGNAL] screen, you can program the operation of the device in the absence of DMX signal. Available options: • ON – all channels will be enabled at 100%; • OFF – all channels will be disabled; •... -
Page 12: Settings
is DMX2/DMX1 – value from the DMX 2 input, if there is a signal on it, if not – DMX 1 input; ź is DMX2/DMX1 CAPTURE – if DMX 1 and DMX 2 are enabled, value from the DMX 2 input is ź... -
Page 13: Curves
5.5.1 Curves 10 curves are available in the device: 5 preset and 5 user-definable. Preset curves can be previewed and copied. User's curves can be edited. The [CURVES] screen includes 10 keys for all the curves: LINEAR, ź REVERSED, ź SWITCHED, ź... -
Page 14: Admin
Only the points for which the values on the x-axis are given incrementally are taken into account, e.g.: CURVE: USER 1 100% entering a value of less than 64 causes that only the first three points are taken into account 5.5.2 Admin Category [ADMIN] contains the administrator settings: restoring the factory default configuration... -
Page 15: Art-Net
The device has 3 users whose access levels are shown in the table below: No logging User Technician Administrator Start screen ü ü ü ü ü ü ü Summary screen Channel preview screen ü ü ü ü ü Scene / Program running Channel setting ü... -
Page 16: Lcd
The following settings are available in the fan menu: information on the operation of fans; red – fans are off, green – fans are on fan operation modes: MODE PROPORTIONAL PROPORTIONAL – the air flow increases linearly ź with the increasing temperature (between the minimum and maximum temperature) HYSTERESIS –... -
Page 17: Installation And Connection Of The Dimmer
6. INSTALLATION AND CONNECTION OF THE DIMMER 6.1 Dimmer view after opening the door Place for mounting Place for mounting the upper air duct the upper air duct Main circuit breakers Master Residual switch current fuse DMX1 IN / OUT slots DMX2 Colours of the current terminals: Power... -
Page 18: Connection Scheme
6.2 Connection scheme OUTPUT CONNECTION DIAGRAM: INPUT CONNECTION DIAGRAM: output 24 Phase wires (L1, L2, L3) Neutral wire N ("zero") Protective wire (PE) Color wires: brown = phase 1 black = phase 2 grey = phase 3 lamp blue = neutral yellow and green = protective The smallest cross section of an The smallest cross section of an... -
Page 19: Installation Steps
6.3 Installation steps All electrical connections must be performed only by adequately qualified personnel!!! 1. Install anchor bolts in the wall according to the dimensions given on page 20. The size and type of anchor bolts depend on the “quality” of the wall. They must be chosen taking into account the weight of the dimmer, so that they would provide a safe and permanent fixing thereof. -
Page 20: External Dimensions And Arrangement Of Mounting Holes
6.4 External dimensions and arrangement of mounting holes DETAIL A: 10,5 dimensions are given in millimetres... -
Page 21: Dmx Signal Connection
7. DMX SIGNAL CONNECTION 1. The recommended cable for the 1. masa connection is RS485 (two wires in a shield). 3. DMX (+) 2. Devices must always be connected in series. 2. DMX (-) 3. To split the DMX line, use the DMX LAST SPLITTER (PX094). -
Page 22: Declaration Of Conformity
12 626 46 92 http://www.pxm.pl 30-701 Kraków fax: 12 626 46 94 DECLARATION OF CONFORMITY according to guide lines 2004/108/WE and 2006/95/WE PXM Marek Żupnik sp. k. Name of producer: ul. Przemysłowa 12 Manufacturer’s address: 30-701 Kraków We declare that our product:...
