B SW
CM
CPOT
EMB
EV
FORW SW
H&S
HORN
HORN SW
LIFT SW
LOW SW
MC
NEMB
NEV
NHORN
NMC
NPC
NPOT
PC
PEMB
PEV
PHORN
PMC
PPC
PPOT
REV SW
SR1
SR2
T SW
The following Codes represent the colours of individual wires used by Zapi (unless
specified otherwise).
A - Orange
B - White
BB - Blue
C - Sky Blue
G - Yellow
GG - Grey
= Belly Switch
= Common Microswitches
= Wiper Potemtiometer
= Electromechanical Brake
= Lowering Valve
= Forward Switch
= Hard & Soft
= Horn
= Horn Switch
= Lifting Switch
= Lowering Switch
= Main Contactor
= Negative Electromechanical Brake
= Negative Lowering Valve
= Negative Horn
= Negative Main Contactor
= Negative Pump Contactor
= Negative Potentiometer
= Pump Contactor
= Positive Electromechanical Brake
= Positive Lowering Valve
= Positive Horn
= Positive Main Contactor
= Positive Pump Contactor
= Positive Potentiometer
= Reverse Switch
= Speed Reduction 1
= Speed Reduction 2
= Tiller Switch

COLOUR CODES (SINGLE COLOURS)

LEGEND

M - Brown
N - Black
R - Pink
RR - Red
V - Green
VV - Purple
