Impressions - Overbed Unit
Assembly Instructions
Dimensions
Width - 228cms
Depth - 41.5cms
Height - 51.5cms
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call Customer Helpline 0844 880 6770
Please keep for future reference
-
642/0110
642/1841
KA5882/02
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 642/0110
Summary of Contents for Argos 642/0110
- Page 1 Impressions - Overbed Unit Assembly Instructions 642/0110 Please keep for future reference 642/1841 Dimensions Width - 228cms Depth - 41.5cms Height - 51.5cms KA5882/02 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call Customer Helpline 0844 880 6770...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2, 3 and 4.
- Page 3 Components - Panels - Exploded Veiw Please check you have all the panels listed below Plan view of panels on page 4 If you have damaged or missing components, Components - Fittings call the Customer Helpline 0844 880 6770 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
- Page 4 Components - Panels - Plan Veiw Please check you have all the panels listed below Corniche/Batton (76 x 8 cm) x 6 Top/base (73 x 39.6cm) x 6 Side (50 x 40 cm) x 6 Shelf (73 x 28 cm) x 3 Back (74.8 x 49.5 cm) x 3 Door...
- Page 5 Assembly Instructions Do not use power/electric screw drivers to attach the hinge plates. Step 1 Please use a normal screw driver to attach it gently as shown here. DO NOT OVERTIGHTEN THE SCREWS AS IT WILL STRIP OUT THE HOLES. Fitting metal dowels Screw metal dowels into panel...
- Page 6 Assembly Instructions Step 3 Cam lock in open Cam lock in closed position position Attaching panels Position top/base and side secure by turning cam locks clockwise Do not over tighten. Position shelf onto side and by turning cam locks clockwise Do not over tighten.
-
Page 7: Back Of Unit
Assembly Instructions Step 5 Attaching panels Position side to top base and shelf secure by turning cam locks clockwise Do not over tighten. Note: Repeat the process on the other two sections. Back of unit Step 6 Important note: Two people required to turn unit over Square up unit Using a tape measure,... - Page 8 Assembly Instructions Step 7 Important note: It is essential that this product is fixed to a wall using the bracket supplied Fixing Safety brackets Postion safety brackets as shown on the back edge of the top secure using screws Note: Repeat the process on the other two sections.
- Page 9 Assembly Instructions Step 9 Important note: To join the robes together, carefully drill through the holes as shown. It is best joining together in position, DO FIRST before attaching to a wall. Connecting to another robe Drill though the holes in unit sides using a 5mm drill bit.
- Page 10 Assembly Instructions Step 11 Attaching panels Secure battons to the wall beneath each cabinet using suitable wall fixing (Wall fixings not supplied) Do not over tighten. For additional support attach the battens to the wall beneath the cabinets (Wall fixings not supplied) Step 12 BACK OF Attaching door hinges...
- Page 11 Assembly Instructions Step 13 Hanging doors Slot door hinges onto hinge plates Tighten screw shown to lock hinges in position (see illustration) Repeat for the other five doors Step 14 ADJUST DOORS Aligning doors To move doors up and down: loosen screws shown and adjust to suit, once doors are aligned re-tighten screws To move doors side to side:...
- Page 12 Assembly Instructions Step 15 Attaching back panels Position corniche onto the and secure using screws Repeat for the other two tops Step 16 Attaching drawer handles Fix handles to door fronts using 19mm bolts Repeat procedure for the remaining doors...
-
Page 13: Customer Helpline
Customer helpline Address: Support Desk, KD Products Ltd, Redwither Tower, Wrexham Industrial Estate, Wrexham, LL13 9XT Tel: 0844 880 6770 e-mail: helpline@kdproducts.co.uk Impressions Overbed Code : B58882C/WW Beech / Dark Maple B5982C/WW Thank you for your purchase!!! In the unlikely event that this product has missing or damaged parts, please fill in the form below and send it to the address above, fax to 01978 661848, or e-mail it to helpline@kdproducts.co.uk.
