Romantic Nest of 2 Tables
Assembly Instructions
Dimensions
Large Table :
Width - 54.5cm
Depth - 36cm
Height - 46.7cm
Small Table:
Width - 38.5cm
Depth - 31cm
Height - 39.4cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future reference
651/8486
Issue 1 - Nov/20/16

Advertisement

loading
Need help?

Need help?

Do you have a question about the Romantic Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Romantic Series

  • Page 1 Width - 38.5cm Depth - 31cm Height - 39.4cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Issue 1 - Nov/20/16...
  • Page 2: Care And Maintenance

    Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce or put weight on the product, the likelihood of components and tools listed on the following pages.
  • Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Back Legs x 2 (44.2 x 4cm) Table Top (54.5 x 36cm) Right leg (44.2 x 4cm) Left leg (44.2 x 4cm)
  • Page 4 Components - Fittings Note: may be supplied than are required. 35mm Screw x 12 50mm Bolts x 16 Allen key x 1 20mm Pads x 8 10mm Spring washer x 16 16mm Flat washer x 16 Tools required Ruler/tape Phillips screwdriver measure (medium &...
  • Page 5 Assembly Instructions Step 1 Attaching legs & strecher Position short stretcher into hole in back leg and Right leg Fix though holes shown using screws Position short stretcher into hole in back leg and Left leg Fix through holes shown using screws Position long stretcher into hole in back leg...
  • Page 6 Assembly Instructions Step 2 Wrong a: Assembly Leg & Top Attached the assembled unit to the table top Using bolt , spring washer and flat washer tightened with allen Note: Put group legs to Table Top with long stretcher direction at back the Table Top b: Attach the pad Remove cover paper on the Remove...
  • Page 7 Assembly Instructions Step 3 Attaching legs & strecher Position short stretcher into hole in back leg and Right leg Fix through holes shown using screws Position short stretcher into hole in back leg and Left leg Fix through holes shown using screws Position long stretcher into hole in back leg...
  • Page 8 Assembly Instructions Step 4 Wrong a: Assembly Leg & Top Position the group Legs & stretcher to Table Top . Using Bolts Spring washer Flat washer Note: Put group legs to Table Top with long stretcher direction at back the Table Top b: Attach the pad Remove cover paper on the .
