Sywell - Bedside
Assembly Instructions -
Dimensions
Width - 38.5cm
Depth - 36cm
Height - 41.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
643/8047
643/8755
643/8171
643/9015
643/8975
615/7263
615/5935
615/5849
MADE IN
BRITAIN
Issue 5 - 12/06/13
