EC03
Robotic Vacuum Cleaner
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eclean EC03 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AGAiT Eclean EC03

Summary of Contents for AGAiT Eclean EC03

  • Page 1 EC03 Robotic Vacuum Cleaner User’s Manual...

  • Page 2: Table Of Contents

    Eclean EC03 User’s Manual Contents Safety Instructions ............3 Safety Notice ....................3 Battery and Recharging Instructions ............3 Notes on UV light..................4 Introduction ..............5 Features ....................5 Package Contents ..................5 Product Overview ..................6 Control Panel .....................7 LED Indicators ...................7 Installing the Side Brush ................8 Installing the Battery .................8...

  • Page 3: Safety Instructions

    Eclean EC03 User’s Manual Safety Instructions Please read the safety notice in the User’s Manual before operating Eclean and keep this manual handy for your future reference. Observe the basic safety rules to prevent any occurrence of electric shock and personal injury.

  • Page 4: Notes On Uv Light

    Eclean EC03 User’s Manual Notes on UV light This device is equipped with Ultraviolet (UV) light to sanitize floor surface while cleaning. • Eclean will turn on the UV light while cleaning, and it will automatically turn off once you pick up the main unit.

  • Page 5: Introduction

    Eclean EC03 User’s Manual Introduction Features • High definition 135° wide-angle lens for broad and vivid video quality. • Negative ions generator that effectively help to freshen and purify the air quality by eliminating most tiny floating particles. • Equipped with Ultraviolet (UV) light to sanitize floor surface while cleaning.

  • Page 6: Product Overview

    Eclean EC03 User’s Manual Product Overview Control Panel Bumper POWER Ethernet port micro-SD cover Memory card slot cover Plane cover Push button Omni wheel Cliff sensor Side brush Side brush Roll brush Cliff sensor Cliff sensor UV light Wheel Wheel...

  • Page 7: Control Panel

    Eclean EC03 User’s Manual Control Panel Camera LED indicators IR LED IR LED POWER CLEAN/STOP button HOME button Press to start/stop Press to return to the POWER button cleaning. recharging dock. Press to turn the device on/off. LED Indicators Icon Function...

  • Page 8: Installing The Side Brush

    Eclean EC03 User’s Manual Getting Started Installing the Side Brush 1. Place Eclean side down on a stable surface. 2. Push the brushes directly onto the holders as shown in the illustration below. Installing the Battery 1. Push the PUSH button to open the plane cover.

  • Page 9: Charging The Battery

    Eclean EC03 User’s Manual Charging the Battery If the battery LED is flashing red, use either the recharging dock or adapter for recharging. Approximate charging time is 4~5 hours. Note: Actual charging time depends on current battery capacity and charging conditions.

  • Page 10: Installing The Memory Card

    Eclean EC03 User’s Manual Installing the Memory Card The installed memory card is used as a buffer storage before Eclean uploads the recorded files to ASUS Webstorage server. 1. Open the memory card slot cover. 2. Insert the micro SD card into the card slot with the gold contacts facing down.

  • Page 11: Starting Operation

    Eclean EC03 User’s Manual Button Description Clean Start cleaning. Press the button repeatedly to switch the cleaning mode. • (Random Wonder) • (Along Wall) • (S Shape) • (Polygonal) • (Spiral) Note: This function is not available in “Max” mode.

  • Page 12: Scheduling Cleaning Time

    Eclean EC03 User’s Manual Scheduling Cleaning Time With this feature, you can configure the weekly cleaning schedule. To set the cleaning schedule, do the following: 1. Press and hold the Plan button until the “Day” icon blinks. start schedule 2. Press the t or u button repeatedly to select the desired field (“Day”, “Cleaning Schedule Number”, or “Start”) and press the p...

  • Page 13: Remote Operation

    Eclean EC03 User’s Manual Remote Operation With RemoteClean application, you can use your smartphones to control Eclean operations wirelessly. List of Supported Devices • Android: Android 4.0 or above • iOS: iOS 4.0 or above Installing RemoteClean Application 1. Launch Play Store (Android devices) or App Store (iOS devices) application.
  • Page 14 Eclean EC03 User’s Manual Android Device 5. Launch RemoteClean application and tap to add the device. Note: • Be sure that your smartphone’s Wi-Fi connection is connected to the same wireless router. • You can add up to 4 devices.
  • Page 15 Eclean EC03 User’s Manual 10. Tap Advanced > Manage Wi-Fi networks. 11. Tap a network to connect to. 12. When connecting to a secured network, enter the password in Wireless password. Then tap OK. 13. After connection is established, disconnect the Ethernet cable.
  • Page 16 Eclean EC03 User’s Manual 9. On the Device List screen, tap to access option menu and select Advanced Setting. 10. Tap Wi-Fi. 11. Tap a network to connect to. 12. When connecting to a secured network, enter the password in Password.

  • Page 17: Operating The Device

    Eclean EC03 User’s Manual Operating the Device On the main screen, tap the device that you want to access its operation. Refer to the illustration below for guideline on operating instructions. Android Device Eclean status Tap to move forward. Live View Tap to move to the left.

  • Page 18: Managing The Device

    Eclean EC03 User’s Manual Managing the Device Change Password Setting You can set the connection password according to your preference. By default, the password is set to “888888”. Android Device 1. On the main screen, tap to access option menu and select Edit Device.

  • Page 19: Video Quality And Lighting Settings

    Eclean EC03 User’s Manual Video Quality and Lighting Settings To ensure the best video quality of the live view, you can select the video quality and specify the lighting frequency that suits with the operating enviroment. 1. Go to Advanced screen.

  • Page 20: Cloud Storage Setting

    Eclean EC03 User’s Manual Cloud Storage Setting Be sure that you have an ASUS WebStorage ID before proceeding with the cloud storage setup. Note: To register an ASUS WebStorage ID, visit https://www.asuswebstorage. com/navigate/login.jsp. Follow the on-screen instructions to complete the account setup.

  • Page 21: Enable Motion Detection

    Eclean EC03 User’s Manual Enable Motion Detection To enable motion detection, do the following: 1. Go to Advanced screen. Android Device • On the main screen, tap to access option menu and select Edit Device > Advanced. iOS Device • On the Device List screen, tap to access option menu and select Advanced Setting.
  • Page 22 Eclean EC03 User’s Manual Android Device Thumbnail View Full Screen iOS Device Thumbnail View Full Screen EN-22...

  • Page 23: Viewing The Recorded Videos

    Eclean EC03 User’s Manual Viewing the Recorded Videos Once motion is detected, the system will automatically record 1-minute video (approximately 2MB) and upload it directly to Asus WebStorage. To view directly the uploaded videos, be sure you have installed ASUS WebStorage APP into your smartphone.

  • Page 24: Reconnecting The Device

    Eclean EC03 User’s Manual Reconnecting the Device When you move Eclean or the wireless router to another place, it may cause Eclean connection to be disconnected. (Android) (iOS) If this happens, tap (Android) or (iOS) to access option menu and select Reconnect to establish the connection.

  • Page 25: Appendix

    Eclean EC03 User’s Manual Appendix Maintenance Cleaning Brushes To clean the side brushes, do the following: 1. Place Eclean side down on a stable surface. 2. Hold the brush hair and pull upward to remove the brushes. 3. Remove hair and dust from the brush.

  • Page 26: Cleaning Dust Bin

    Eclean EC03 User’s Manual Cleaning Dust Bin 1. Push the PUSH button to open the plane cover. 2. Take out the dust bin from Eclean. 3. Open the dust bin filter. 4. Throw away the dust and dirt from the dust bin.

  • Page 27: Troubleshooting

    Eclean EC03 User’s Manual Troubleshooting General Problem Cause of failure Solution Eclean won’t start • The recharging • Adjust the recharging charging after dock is not dock position. returning to the attached to the • Check the battery recharging dock.

  • Page 28: Error Indicators

    Eclean EC03 User’s Manual Error Indicators Error indication Cause of failure Solution Flashes red once Dust bin is not in Make sure the dust bin every four seconds place is properly installed. Flashes red twice Foreign objects in Remove foreign...

  • Page 29: Product Warranty

    4. During the warranty period, parts or products may be repaired or replaced with repaired parts or products of similar functions. AGAiT will return the repaired product or a replacement with similar functions to customers. All faulty parts or units removed from the product shall become the properties of AGAiT.
  • Page 30 AGAiT will inform consumers of the time, place and manner of returning the faulty Eclean. If the warranty of the faulty Eclean is still valid, AGAiT will be responsible for all delivery fees. 8. If the consumer have lost the warranty card, purchasing invoice,...

  • Page 31: Customer Copy

    • Your complete address and contact information. 4. To guarantee your after-sales service rights, please register your product online within one month after your purchase. After registration, you can become an AGAiT member and enjoy more exclusive membership benefits (Taiwan only). EN-31...
