SET COMMUNICATION:

By Pressing the "Set Communication" button from the main window for SW67D17 (Fig. 2)
the window "Set Communication" appears (Fig. 3).
The means of the fields for the "LoRaWAN" section are:
In the field "RF Band" the wireless band used for LoRaWAN communication is
defined;
In the field "Network Type" the type of LoRaWAN network is defined;
If the field "Adaptive Data Rate" is checked, the converter will enable the ADR
functionalities to select the best data rate to be used in relation to the environmental
conditions;
In the field "Data Rate" the data rate for LoRaWAN communication is defined;
In the field "Transmission
In the field "Max Payload
is defined (fixed in relation to the data rate selected);
In the field "Activation
defined;
In the field "Device Address" the device identifier (DevEUI) is defined (only for ABP
method);
In the field "Application
(only for ABP method);
In the field "Network Session
LoRaWAN gateway (NwkSKey) is defined (only for ABP method);
In the field "Application Session
payload (AppSKey) is defined (only for ABP method);
If OTAA method is selected, in the field
dynamic activation of the converter in the LoRAWAN network is defined.
ADFweb.com S.r.l.
Type" the type of LoRaWAN communication is defined;
Size" the maximum dimension of the LoRaWAN messages
Method" the method used to join into a LoRaWAN network is
Identifier" the application identifier (AppEUI) is defined
Key" the key used for the communication with the
Key" the key for encryption and decryption of the
"Application
User Manual LoRaWAN / BACnet Slave
Document code: MN67D17_ENG
Key" the secret key for the
Revision 1.000
Figure 3a: "Set Communication" window
Page 18 of 31
