In the section "BACnet Master" it is possible to select the type of BACnet to use from:
BACnet/IP (it uses Ethernet);
BACnet MS/TP (it uses RS485).
If selected "BACnet/IP" the means of the fields for "BACnet" are:
In the fields "IP ADDRESS" the IP address of BACnet/IP side of the converter is defined;
In the fields "SUBNET
defined;
In the fields "GATEWAY" the default gateway of the network is defined. This feature can
be enabled or disabled pressing the Check Box field. This feature is used for going out of
the net;
In the field "Port" the port used for BACnet communication is defined. The default port
used for BACnet communication is 47808, but is possible to insert any value;
In the field "BACnet Device
defined;
In the field "Device Identifier" the device instance of BACnet/IP side of the converter is
defined;
If the field "BACnet description up to 32
BACnet objects can be up to 32 chars.
If selected "BACnet MS/TP" the means of the fields for "BACnet" are:
In the field "Baudrate" the baudrate of BACnet MS/TP side of the converter is defined;
In the field "Parity" the parity of BACnet MS/TP side of the converter is defined;
In the field "BACnet Device
defined;
In the field "MAC Address" the MAC of BACnet MS/TP side of the converter is defined;
The field "Max Masters" specifies the highest allowable address for master nodes. The
value shall be less than or equal to 127;
The field "Max Info Frames" specifies the maximum number of information frames the
node may send before it must pass the token;
In the field "Device Istance" it is possible to assign a number to the BACnet node (used
for the Device Istance);
ADFweb.com S.r.l.
Mask" the SubNet Mask of BACnet/IP side of the converter is
Name" the name of BACnet/IP side of the converter is
chars" is checked, the description of the
Name" the name of BACnet MS/TP side of the converter is
User Manual LoRaWAN / BACnet Slave
Document code: MN67D17_ENG Revision 1.000
Figure 3b: "Set Communication" window
