Retro Pedestal - Tall Unit
Assembly Instructions -
Dimensions
Width - 49.5cm
Depth - 39.5cm
Height - 152cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
309/1951
MADE IN
BRITAIN
Issue 1 - 28/11/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 309/1951
Summary of Contents for Argos 309/1951
- Page 1 Retro Pedestal - Tall Unit Assembly Instructions - 309/1951 Please keep for future reference Dimensions Width - 49.5cm Depth - 39.5cm MADE IN Height - 152cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 30kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below 3 Top Fixed Shelf (DF1109) (DF1118) (494 x 392mm) (460 x 388mm) Left End Right End Base...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 7 Prepare the left side Tap 2 wooden dowels into the left Finished side front edge Note: Wooden dowels must not stick out from 10mm the edge by more than 10mm or they may damage other panels. Place a runner on the left side...
- Page 8 Assembly Instructions Step 8 Prepare the right side Tap 2 wooden dowels into the right side Place a runner on the right side as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Finished front edge...
- Page 9 Assembly Instructions Step 9 Prepare the 2 fixed shelves Tap 4 wooden dowels into each of the 2 fixed shelves Finished Insert 4 large locking front edge nuts into each of the 2 fixed shelves Step 10 Fit a fixed shelf to the right side Push a fixed shelf onto the right side...
- Page 10 Assembly Instructions Step 12 Fit the left side Push the left side onto the fixed shelves Use a screwdriver to tighten the 2 large locking nuts fitted to each of the fixed shelves Finished front edge Step 13 Fit the base Attach the base the left side and the...
- Page 11 Assembly Instructions Step 14 Fit the feet Fit the 4 feet to the base using screws and tighten them using the allen key Note: You may find it easier to turn the foot as the screw is held with the allen key. Step 15 Fit the rail Attach the rail...
- Page 12 Assembly Instructions Step 17 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted the left side and the right side Step 18 The measurement from top corner X to bottom corner X must be Fit the back equal to the measurement from top corner Y to bottom corner Y Square up the unit by...
- Page 13 Assembly Instructions Step 19 Fit the loose shelves and the drawer For each of the 2 loose shelves insert 4 shelf studs , as shown. Lower the 2 loose shelves down onto the shelf studs Slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer...
- Page 14 Assembly Instructions Step 21 Fit the door and door stop Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
- Page 15 Assembly Instructions Step 22 Adjust the door if needed Before adjusting the door, use a spirit level to check the top (or base) of the unit is level, front- to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any...
- Page 16 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3118...
