Argos Romana 305/1850 Assembly Instructions Manual

Argos Romana 305/1850 Assembly Instructions Manual

3 drawer chest

Advertisement

Quick Links

Romana - 3 Drawer Chest
Assembly Instructions
Dimensions
Width - 80cm
Depth - 42.6cm
Height - 82cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
- Please keep for future reference
Customer Helpline: 08456 400 800
305/1850
305/1867
Issue 1 - 25/04/13

Advertisement

loading
Need help?

Need help?

Do you have a question about the Romana 305/1850 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argos Romana 305/1850

  • Page 1 Romana - 3 Drawer Chest Assembly Instructions - Please keep for future reference 305/1850 305/1867 Dimensions Width - 80cm Depth - 42.6cm Height - 82cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 25/04/13...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not from natural timber; you may recommend the components and tools listed on pages 2 and 3. notice some variation in the grain use of power and colour of different component...
  • Page 3 Components - Panels Please check you have all the panels listed below Drawer bottom x 3 (65 x 32.6cm) 1 Top panel (80 x 42.6cm) 9 Drawer front x 3 (66.4 x 17.6cm) 2 Right side panel (80 x 39.8cm) 10 Drawer side x 6 (34 x 14cm) Drawer back x 3...
  • Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 Assembly Instructions Step 1 Fixing right front frame to the right side panel (Two people required for an easier assembly) Insert right side panel into right front frame through joints. Yes! Note: 60mm Before fixing the Attention! 66mm blocks into place it is important to ensure that the slot and 503mm...
  • Page 6 Assembly Instructions Step 3 Fitting Metal dowels. Screw metal dowels into top panel Note: Insert metal dowels as far as shown. Do not over tighten. Step 4 Insert dowels into the indicated parts.
  • Page 7 Assembly Instructions Step 5 Fixing side drawer runners. it side drawer runners to the right side panel then fix it using screws as shown. Repeat step 5 for the left side panel and side drawer runners. Step 6 Assembling the cabinet. Insert top front frames and bottom front frame...
  • Page 8 Assembly Instructions Step 7 Assembling the cabinet. Place right side panel properly ensuring front frames are all fitted into their holes at the same time. Fix bottom front frame to the right and left side panels using screws as shown in the diagram.
  • Page 9 Assembly Instructions Step 9 Fixing top panel. With help, fit top panel to the cabinet. Insert 4 locking nuts into side panels where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten. Important: After fixing the top panel, with help, carefully lay down the product.
  • Page 10 Assembly Instructions Step 11 Drawer assembly. Attach drawer sides to the drawer front using screws Slide drawer bottom into slots on drawer sides and position drawer back in place. Carefully lay down the drawer holding drawer back , press the drawer sides and fix them using screws Attach handle...
  • Page 11 Assembly Instructions Step 13 Fixing back panels. Important: Cabinet MUST ‘square’ when back panels are attached. Attach the right back panel first using nails Position profile onto back panel (just attach). Carefully slot the second back panel into the profile and fix it to the cabinet using nails Step 14 Fixing to wall.
  • Page 12: A Guide To - Wall Mounting & Fixings

    A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.

This manual is also suitable for:

Romana 305/1867
