Romana - Bedside Chest
Assembly Instructions
Dimensions
Width - 42cm
Depth - 36cm
Height - 55cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
- Please keep for future reference
Customer Helpline: 08456 400 800
305/1836
305/1843
Issue 1 - 25/04/13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Romana 305/1836
Summary of Contents for Argos Romana 305/1836
- Page 1 Romana - Bedside Chest Assembly Instructions - Please keep for future reference 305/1836 305/1843 Dimensions Width - 42cm Depth - 36cm Height - 55cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 25/04/13...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not from natural timber; you may recommend the components and tools listed on pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below 5 Right front frame (53.4 x 4.5cm) 6 Left front frame (53.4 x 4.5cm) 1 Top panel (42 x 36cm) underside 8 Drawer bottom (28.6 x 27cm) 7 Base panel (34.4 x 31.4cm) 2 Right side panel (53.4 x 33cm)
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Fixing right front frame to the right side panel (Two people required for an easier assembly) Insert right side panel into right front frame through joints. Yes! Note: Attention! Before fixing the 130mm blocks into 66mm place it is important to ensure that the slot and 272mm...
- Page 6 Assembly Instructions Step 3 Insert dowels into the indicated parts. Step 4 Fitting Metal dowels. Screw metal dowels into top panel and side panels Note: Insert metal dowels as far as shown. Do not over tighten.
- Page 7 Assembly Instructions Step 5 Fixing side drawer runner. Fit side drawer runner to the right side panel then fix it using screws as shown. Repeat step 5 for the left side panel and side drawer runner. Step 6 Assembling the cabinet. Insert top front frame and bottom front frame into holes on left side...
- Page 8 Assembly Instructions Step 8 Assembling the cabinet. With help, fit left side panel to the base panel and front frames as shown. Insert 2 locking nuts into base panel where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten.
- Page 9 Assembly Instructions Step 10 Fix side plinths the side panels using screws Note: Make sure side plinths are aligned to the bottom and front edges of the side panels. Fix front plinth to the bottom front frame using screws Note: Make sure front plinth is aligned to the...
- Page 10 Assembly Instructions Step 12 Drawer assembly. Attach drawer sides to the drawer front using screws Slide drawer bottom into slots on drawer sides and position drawer back in place. Carefully lay down the drawer holding drawer back , press the drawer sides and fix them using screws Attach handle...
