VII. ZONES
10. BLOCK DIAGRAM – ZONES MENU
This submenu enables the user to configure operation parameters for particular zones.
11.

OFF/ON

After the room sensor has been connected and registered in a given zone, it is used by EU-L-7E controller. The default
setting for this option is <OFF>. It may be activated when the room sensor has been connected.
12.

PRE-SET TEMPERATURE

The pre-set zone temperature depends on the weekly schedule settings. However, this function enables the user to change
this value separately. After the value has been set, the user defines how long the temperature should apply. When the time
elapses, the pre-set temperature will depend on the weekly schedule again.
After pressing MENU button in this submenu, the display shows application time screen (permanent, temporary).
The main screen displays current pre-set temperature value and the time left (see: Main screen description).
13.

WEEKLY CONTROL

EU-L-7E controller offers two types of weekly schedules:
Own – local schedule
This weekly schedule is assigned to a given zone only. After the room sensor has been detected by the external controller,
the schedule is activated automatically in this zone and may be adjusted by the user to individual needs.
OFF
ON
Pre-set temperature
Weekly control
Operation mode
Calibration
Hysteresis
14
Own
Schedules 1-5
Heating/Cooling
Only cooling
Only heating
