Matrix COSEC ATOM RD300 Quick Installation Manual page 6

B. Non-Concealed Wiring
1. Follow the Step 1 and Step 2 as explained for the Concealed
Wiring and fix the mounting plate on the wall.
(For non-concealed wiring, you do not need to drill the area D.)
Figure 13
2. Unscrew the Back Plate screw with the help of screwdriver
and remove the Back Plate.
11
3.Pull out the Cables from the Back Plate hole and lead the cables
outside from the bottom opening of COSEC ATOM, as illustrated
in Figure 14.
4. Connect the necessary cables and align the COSEC ATOM
body with the Mounting Plate.
Back Plate
Figure 14
12
