Please read this guide first for correct installation and retain it for future reference. The information
in this guide is prevailing at the time of publication. However, Matrix Comsec reserves the right to
make changes in product design and specifications without prior notice.
Copyright
All rights reserved. No part of this document may be copied or reproduced in any form or by any
means without the prior written consent of Matrix Comsec.
Warranty
Limited Warranty. Valid only if primary protection is provided, mains supply is within limit and
protected, and environment conditions maintained within product specifications. Complete
warranty statement is available on our website:
www.matrixaccesscontrol.com
3
Know your ATOM
Ÿ
COSEC ATOM is a slave reader which can work with COSEC ARGO,
4
COSEC VEGA, COSEC PATH V2 using RS-232 and with COSEC ARC
DC200 using RS-485. It can also work with 3 party Wiegand
6
Interface.
Ÿ
6
It is an intelligent compact Access Control Device which supports
Bluetooth and Card Credentials for
7
Attendance.
Ÿ
COSEC ATOM has three main variants that contains either Matrix FP
29
sensor(MF) or Suprema Sensor(SF). The respective variants are
listed below,
31
35
Type 1: COSEC ATOM RD300
1
2
Figure 1: Front View
Access Control and Time &
1. Display Screen
2. Finger Sensor
3
3. Mounting Screw Hole
4. Cable Assembly
4
5. Mounting Plate
Sub Variants
3
* ATOM RD300SFE
5
* ATOM RD300MFE
Ÿ ATOM RD300MFM
3
Ÿ ATOM RD300MFI
Ÿ ATOM RD300SFM
Ÿ ATOM RD300SFI
Figure 2: Back View
rd
4
