- Page 1 ASSEMBLY INSTRUCTIONS : HAMPTON DESK Description : OF-67X Item No. ITEM NO.: OF-67X Printed in Vietnam REVISED APR 03, 2019 - 1 -...
-
Page 2: Before Assembly
Protect the surface of the table with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: OF-67X Printed in Vietnam REVISED APR 03, 2019 - 2 -... -
Page 3: Part List
FINISHED ITEM ONLY Pan head screw Large Flat Washer *Metal knob: (M4x22mm) (6.5 x 19mm) *Wooden knob: (M4x25mm) Small Flat Washer Screw (6.5 x 13mm) (M4 x 45mm) ITEM NO.: OF-67X Printed in Vietnam REVISED APR 03, 2019 - 3 -... - Page 4 Attach side frames (B) to the top (A) with bolts (1) and (2), and washers (3), (4) and (5) as shown below. Tighten with Allen key (6). Insert crossbar (C) into side frames (B) and attach with screws (9) as shown below. Tighten with a screwdriver. ITEM NO.: OF-67X Printed in Vietnam REVISED APR 03, 2019 - 4 -...
- Page 5 STEP 2 Attach knob (7) to front of drawer with pan head screw (8) as shown below. Tighten with a screwdriver. ITEM NO.: OF-67X Printed in Vietnam REVISED APR 03, 2019 - 5 -...
