- Page 1 ASSEMBLY INSTRUCTIONS Description : 2 DRAWER COUNTRY ACCENT TABLE Item No. : OT-66 ITEM NO : OT-66 Printed in Vietnam REVISED NOV 06, 2014 - 1 -...
- Page 2 Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your table. Protect the surface of the table with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO : OT-66 Printed in Vietnam REVISED NOV 06, 2014 - 2 -...
- Page 3 Back panel Front apron Upper Back apron Drawer front Upper Upper Drawer side Drawer back Lower Lower Drawer front Drawer side Lower Drawer Drawer back bottom Rail ITEM NO : OT-66 Printed in Vietnam REVISED NOV 06, 2014 - 3 -...
- Page 4 (K4x80mm) STEP 1 Attach side panel (B) to top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (7). ITEM NO : OT-66 Printed in Vietnam REVISED NOV 06, 2014 - 4 -...
- Page 5 Tighten with a screwdriver. Attach side panel (B) to top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (7). ITEM NO : OT-66 Printed in Vietnam REVISED NOV 06, 2014 - 5 -...
- Page 6 Then attach drawer side (J) to the unit with screws (4) as shown below. Tighten with a screwdriver. Attach rail (M) to drawer front (K) and drawer back (I) with screws (4). Tighten with a screwdriver. ITEM NO : OT-66 Printed in Vietnam...
- Page 7 STEP 6 Put drawers into the unit as shown below. Attach knobs (6) to front of drawer with pan head screws (5). Tighten with a screwdriver. ITEM NO : OT-66 Printed in Vietnam REVISED NOV 06, 2014 - 7 -...
