EMOJO Caddy Assembly Instructions Manual page 12

A) The rear caliper cables are already routed all the way into the main frame, Iden/fy the led from the
right cable.
B) The cables must be routed under the rear axle
C) Pass each cable end thru the caliper guide (C), the rubber sleeve of the cable will not go any further.
Loosen the cable screw on the caliper (D) and insert the naked sec/on of the cable thru as shown in
the picture, gently pull the cable and adjust how much of the cable length comes to the other side to
determine the brake adjustment
D) Tighten the cable security screw.
(A)
REAR
BRAKES
Rear brake cables coming out
of the frame.
(B)
(C)
(D)
