Assembling the 700C Cycle (Upright)

Parts List for the 700C Cycle

Part# Qty
LT-03151
HX-00438
HS-41109
HS-41072
HS-41126
PL-51670
HW-53018
AX-61026
AW-61033
AX-61351
AF-61434
AX-61423
AX-70387
Varies
Varies
Varies

Attaching the Display Upright

See Figure 4 (located on the next page) for this step. Lay the display upright on the ground
and plug the ribbon cable from the upright to the ribbon cable in the chassis. Tuck the cables
inside the chassis upright tube to make sure they don't get pinched when you attach the
upright. Slide the upright down over the upright on the chassis. Using a 3/16" hex wrench,
secure them with three 5/16" by 1" button-head screws (HS-41126) and washers (HW-53018).
NOTE: Do not overtighten the screws for attaching the upright tube. The screws should be
tightened only enough to securely attach the upright tube without movement.
Stand up the chassis/display upright combination.
Description
1 Owner's Manual
1 Wrench, 3/16 Hex Key
9 #10-24 x 1/2" Screw
4 5/16-18 x 3/4" Button Head Screw
3 5/16-x 1" Button Head Screw
1 Water Bottle Holder
7 5/16" Split Lock Washer
1 Termination Plug
1 Communications Cable
1 Handlebar (no CardioTouch) or
1 Handlebar (for CardioTouch)
1 CardioTouch Handlebar (optional)
1 Display Upright
1 Configuration Kit
1 Display Console
1 Main Chassis Base
