Cybex 700C Cycle and 700R Recumbent Owner's Manual

Assembling the 700R Recumbent Cycle

Parts List for the 700R Recumbent Cycle
The following parts are included with 700R Recumbent Cycle:
Part#
Qty
LT-03151
HX-00438
HS-13948
HS-41107
HS-41109
PL-51670
HW-53018
AX-61026
AW-61033
AX-61309
AX-62014
Varies
Varies
Varies
Please refer to Figure 1 (shown below) for "Attach Seat Back Assembly" and "Attach the
Display Upright" sections listed on the next page.
Figure 1
Description
1
Owner's Manual
1
Wrench, 3/16 Hex Key
3
5/16-18 x 3/8" Cap Screw
4
5/16-18 x 1-1/2" Cap Screw
7
#10-24 x 3/4" Screw
1
Water Bottle Holder
7
Lock Washer
1
Termination Plug
1
Communications Cable
1
Seat Back Assembly
1
Display Upright
1
Configuration Kit
1
Display Console
1
Main Chassis Base
Page 2-2
