9.1 USB
Pin
Function
Type
1
VUSB
Power
2
D-
Differential
3
D+
Differential
4
ID
Analog
5
GND
Power
9.2 Headers
The board exposes two 15 pin connectors which can either be assembled with pin headers or soldered through castellated vias.
Pin
Function
Type
1
D13
Digital
2
+3V3
Power Out
3
AREF
Analog
4
A0/DAC0
Analog
5
A1
Analog
6
A2
Analog
7
A3
Analog
8
A4/SDA
Analog
9
A5/SCL
Analog
10
A6
Analog
11
A7
Analog
12
VUSB
Power In/Out
13
RST
Digital In
14
GND
Power
15
VIN
Power In
16
TX
Digital
17
RX
Digital
18
RST
Digital
19
GND
Power
20
D2
Digital
21
D3/PWM
Digital
22
D4
Digital
23
D5/PWM
Digital
24
D6/PWM
Digital
25
D7
Digital
26
D8
Digital
27
D9/PWM
Digital
28
D10/PWM
Digital
29
D11/MOSI
Digital
30
D12/MISO
Digital
9.3 Debug
On the bottom side of the board, under the communication module, debug signals are arranged as 3x2 test pads with 100 mil pitch with pin 4 removed. Pin 1 is depicted in
Figure 3 – Connector Positions
Pin
Function
Type
1
+3V3
Power Out
2
SWD
Digital
3
SWCLK
Digital In
5
GND
Power
6
RST
Digital In
9 / 12
Description
Power Supply Input. If board is powered via VUSB from header this is an Output (1)
USB differential data -
USB differential data +
Selects Host/Device functionality
Power Ground
Description
GPIO
Internally generated power output to external devices
Analog Reference; can be used as GPIO
ADC in/DAC out; can be used as GPIO
ADC in; can be used as GPIO
ADC in; can be used as GPIO
ADC in; can be used as GPIO
ADC in; I2C SDA; Can be used as GPIO (1)
ADC in; I2C SCL; Can be used as GPIO (1)
ADC in; can be used as GPIO
ADC in; can be used as GPIO
Normally NC; can be connected to VUSB pin of the USB connector by shorting a jumper
Active low reset input (duplicate of pin 18)
Power Ground
Vin Power input
USART TX; can be used as GPIO
USART RX; can be used as GPIO
Active low reset input (duplicate of pin 13)
Power Ground
GPIO
GPIO; can be used as PWM
GPIO
GPIO; can be used as PWM
GPIO, can be used as PWM
GPIO
GPIO
GPIO; can be used as PWM
GPIO; can be used as PWM
SPI MOSI; can be used as GPIO
SPI MISO; can be used as GPIO
Description
Internally generated power output to be used as voltage reference
nRF52480 Single Wire Debug Data
nRF52480 Single Wire Debug Clock
Power Ground
Active low reset input
