10 Mechanical Information

10.1 Board Outline and Mounting Holes

The board measures are mixed between metric and imperial. Imperial measures are used to maintain 100 mil pitch grid between pin rows to allow them to fit a breadboard
whereas board length is Metric

11 Certifications

11.1 Declaration of Conformity CE DoC (EU)

We declare under our sole responsibility that the products above are in conformity with the essential requirements of the following EU Directives and therefore qualify for
free movement within markets comprising the European Union (EU) and European Economic Area (EEA).
11.2 Declaration of Conformity to EU RoHS & REACH 211 01/19/2021
Arduino boards are in compliance with RoHS 2 Directive 2011/65/EU of the European Parliament and RoHS 3 Directive 2015/863/EU of the Council of 4 June 2015 on the
restriction of the use of certain hazardous substances in electrical and electronic equipment.
Substance
Lead (Pb)
Cadmium (Cd)
Mercury (Hg)
Hexavalent Chromium (Cr6+)
Poly Brominated Biphenyls (PBB)
Poly Brominated Diphenyl ethers (PBDE)
Bis(2-Ethylhexyl} phthalate (DEHP)
Benzyl butyl phthalate (BBP)
Dibutyl phthalate (DBP)
Diisobutyl phthalate (DIBP)
Exemptions : No exemptions are claimed.
Arduino Boards are fully compliant with the related requirements of European Union Regulation (EC) 1907 /2006 concerning the Registration, Evaluation, Authorization and
Restriction of Chemicals (REACH). We declare none of the SVHCs (https://echa.europa.eu/web/guest/candidate-list-table), the Candidate List of Substances of Very High
Concern for authorization currently released by ECHA, is present in all products (and also package) in quantities totaling in a concentration equal or above 0.1%. To the best
of our knowledge, we also declare that our products do not contain any of the substances listed on the "Authorization List" (Annex XIV of the REACH regulations) and
Substances of Very High Concern (SVHC) in any significant amounts as specified by the Annex XVII of Candidate list published by ECHA (European Chemical Agency) 1907
/2006/EC.
10 / 12
Board layout
Arduino® Nano 33 BLE Sense / Rev. 01 - 03/12/2021
Arduino® Nano 33 BLE Sense
Maximum limit (ppm)
1000
100
1000
1000
1000
1000
1000
1000
1000
1000
