Contec CONPROSYS CPS-MCS341-DS1-111 Reference Manual

M2m controller cpu module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Reference Manual
(Hardware)
M2M Controller CPU Module
CPS-MCS341-DS1-111
CPS-MCS341-DS1-131
CONTENTS
Introduction .................................................................. 4
Safety Precautions .................................................... 13
Product Nomenclature and Function................ 22
Setup ............................................................................. 34
Installation ................................................................... 36
Appendix ...................................................................... 56
Optional Products .................................................... 66
Customer Support and Inquiry ........................... 68
Index .............................................................................. 70

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONPROSYS CPS-MCS341-DS1-111 and is the answer not in the manual?

Questions and answers

Related Manuals for Contec CONPROSYS CPS-MCS341-DS1-111

Summary of Contents for Contec CONPROSYS CPS-MCS341-DS1-111

  • Page 1 Reference Manual (Hardware) M2M Controller CPU Module CPS-MCS341-DS1-111 CPS-MCS341-DS1-131 CONTENTS Introduction ..............4 Safety Precautions ............ 13 Product Nomenclature and Function....22 Setup ................34 Installation ..............36 Appendix ..............56 Optional Products ............ 66 Customer Support and Inquiry ......68 Index ................

  • Page 2: Table Of Contents

    Table of Contents Introduction ............... 4 1. Related Manuals ..............................5 2. Check the Firmware Version ..........................6 3. About the Product ..............................7 4. Interface Within ............................... 8 5. Features ..................................9 1. Hardware features............................9 2. Software Features ............................10 6.
  • Page 3 Table of Contents 3. Setting the Configurable Type Module ....................44 2. Connecting to an External Device ......................... 48 3. Cable Connection ..............................50 1. Power ................................. 50 2. LAN ..................................51 3. RS-232C ................................51 4. Digital Input ..............................53 5.

  • Page 4: Introduction

    Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. — 4 —...

  • Page 5: Related Manuals

    (Printed matter) package. and describes the precautions. Setup Manual Download from Read this when setting up the This describes the required items for the Contec product. setup and configuration procedure. website (PDF) Reference Manual Download from Read this when operating the...

  • Page 6: Check The Firmware Version

    Before start using the product, visit our website to check the firmware version and update to the latest one if necessary. Updating firmware to the latest version will resolve troubles and stabilize the operation. https://www.contec.com/download/ Download Refer to the "Reference Manual (Software)" for the details of the firmware updating.

  • Page 7: About The Product

    — — Introduction CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 3. About the Product CPS-MCS341-DS1-111 and CPS-MCS341-DS1-131 are M2M controllers with isolated digital input and output (Input : 4ch, Output : 4ch), RS-232C, LAN interface, and Ethernet Hub. As you desire, add the configurable type modules of our CONPROSYS series. All the processes from development to operation can be performed on a web browser.

  • Page 8: Interface Within

    — — Introduction CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 4. Interface Within This product is a M2M controller with the following interfaces. Analog Output SD Card Analog Input Digital Input Digital Output ［Current］ Slot ［Current］ Analog Output 3GSIM Analog Input RS-422A/485 RS-232C Counter ［Voltage］...

  • Page 9: Features

    — — Introduction CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 5. Features 1. Hardware features  Add configurable modules (Common to all models) This product allows you to install modules from a wide variety of types to suit the needs of the user. * Up to 16 modules can be set and the total current consumption should be less than 3.3A.

  • Page 10: Software Features

    The product has LED for an operation check, which helps you visually confirm the communication status of each interface.  No electrolytic capacitor battery (Common to all models) No electrolytic capacitor is used. The Contec is creating the product with a longer life. 2. Software Features  Together with OPC UA Server (CPS-MCS341-DS1-131) OPC UA (Unified Architecture) is an advanced model of OPC specifications, which presents refined capability of transmitting and receiving semantic description data.
  • Page 11 — — Introduction CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware)  Message communication function (Common to all models) With the RS-232C or the Ethernet device (TCP/UDP), up to 10 links can be set to send or receive messages. Message communication can be accomplished from Web task script. ...

  • Page 12: Product Configuration List

    This product is verified in conformity with our recommended power supply. In case you use  other power supplies, thus, it may not be able to fulfil certification requirements. Please see the Contec website regarding power supply recommendation (https://www.contec.com/). — 12 —...

  • Page 13: Safety Precautions

    Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. — 13 —...

  • Page 14: Safety Information

    — — Safety Precautions CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely. DANGER indicates an imminently hazardous situation which, if not DANGER avoided, will result in death or serious injury.

  • Page 15: Handling Precautions

    — — Safety Precautions CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 2. Handling Precautions DANGER Do not use the product in locations exposed to a flammable or corrosive gas. It may cause  explosion, fire, electrical shock, or malfunction. Do not allow the device to come into contact with foreign substances (metal particles, ...
  • Page 16 When removing connectors or cables, always unplug the power cables and confirm the LEDs  are turned off. Do not modify the product. CONTEC will bear no responsibility for any problems, etc.,  resulting from modifying the product. In the event of failure or abnormality (foul smells or excessive heat generation), unplug the ...
  • Page 17  damage. To prevent the disconnection, always mount both of them on DIN rail for operations. Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever  (Including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein.
  • Page 18 Lors du dépôt de connecteurs ou de câbles, toujours débrancher les câbles d’alimentation de  l’unité centrale et confirmer la mise hors tension des DEL. Ne pas modifier le produit. CONTEC ne pourra être tenue responsable de tout problème, etc.,  issu de la modification du produit.
  • Page 19 Lors d’un fonctionnement du produit sans interruption, s’assurer de lire le manuel du site Web CONTEC et d’assimiler le contenu. Lorsque le produit est utilisé à un endroit influencé par une surintensité ou une surtension ...

  • Page 20: Fcc Part15 Subpart B Class A Notice

    — — Safety Precautions CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 1. FCC PART15 Subpart B Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 21: Battery Handling And The Storage In Eu Signatory

    — — Safety Precautions CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 3. Battery handling and the storage in EU signatory This symbol mark is for EU countries only. This symbol mark is according to the directive 2006/66/EC Article 20 Information for end-users and Annex II.

  • Page 22: Product Nomenclature And Function

    Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. — 22 —...

  • Page 23: Nomenclature Of Product Components

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 1. Nomenclature of Product Components Component names of the product are shown in the figure below. CPS-MCS341-DS1 -111 CPS-MCS341-DS1 -131 (Inside) (Inside) 24V DC 24V DC MCOM MCOM DIO0 DIO0 DIO1 DIO1...

  • Page 24: Description Of Product Components

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 2. Description of Product Components Components such as connectors, switches are described. 1. Stack Bus It is used for power supply and communication to the configurable type module. CAUTION Never set or remove the product while power is active.

  • Page 25: Led Indicator

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 4. LED Indicator Status of the product is indicated by ON/OFF and flashing of LED. The meaning of each LED is described below.  LED Indicator 1 Color and Description Color Display Description...

  • Page 26: Rotary Switch

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 5. Rotary Switch For both H and L of ID, use with the setting [00]. — 26 —...

  • Page 27: Digital Input/Digital Output Connector

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 6. Digital Input/Digital Output Connector This product has 4 channels of digital input and 4 channels of digital output. You can switch them as digital input or digital output. Use the 6-pin connector, included in the package to connect to external power.

  • Page 28: Lan Port

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 7. LAN Port This product has 2 ports of Ethernet LAN Port. As the LAN port of this product is set in HUB mode, it is recognized as one port from OS. Ethernet Hub function in this product is the switching hub.
  • Page 29 — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) CAUTION HUB mode of this product might be slower than other standard switching HUB products. If a large amount of data or high-speed response is requested, an external switching HUB will be required.

  • Page 30: Dip Switch

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 8. DIP switch  DIP Switch 1 It is used for user setup. *The factory default of all switches are set to “OFF”. *Refer to the Reference Manual (Software) for switch setting. ...

  • Page 31: Power Switch

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 9. Power Switch It controls the power supply. Pin Assignment Operation Description Press it for a short time: To turn off the power. Press it for a while: To restart the product. 10.

  • Page 32: Usb Port

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 11. USB Port The product has 1 port of USB interface of TYPE-A. Pin Assignment Pin No. Signal Name USB_VCC DATA- DATA+ USB_GND CAUTION If you use the USB device with bus power, the ambient temperature should be 55 °C or lower. ATTENTION Si vous utilisez le dispositif USB avec alimentation par bus, la température ambiante devrait être de 55 °C ou moins.

  • Page 33: Rs-232C Serial Port

    — — Product Nomenclature and Function CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 12. RS-232C Serial Port This product has 1port of RS-232C compliant serial interface. 9-pin D-SUB (MALE) is used for this product. The baud rate is 115,200bp (Max) 9-pin D-SUB (Male) No.4-40UNC inch nut Pin Assignment...

  • Page 34: Setup

    Setup This section describes how to set a SD card that is necessary to operate the product. — 34 —...

  • Page 35: Insert Sd Card

    — — Setup CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 1. Insert SD Card With the terminal side is in the position shown below (see the figure), insert the SD card all the way into the slot. Terminal side *Reverse the procedure described in the "Insert SD card "to remove the card. —...

  • Page 36: Installation

    Installation This section describes how to mount the product on a DIN rail, and to connect to an external device with a cable. — 36 —...

  • Page 37: Install The Product

    — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 1. Install the Product 1. Installation Conditions  Installation Orientation Install the product in the orientations shown below (0 °C). Other orientations may cause problems such as malfunctions due to inadequate heat dissipation. Orientation for DIN rail Mounting —...
  • Page 38 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware)  Ambient Temperature The ambient temperature is decided from the multiple measurement points which are a 50mm- distance from the product. During the operation, adjust the air current to make certain that the temperatures measured in the points stay within the specified temperature.
  • Page 39 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) CAUTION Note that although the ambient temperature is within the specified range, an operational  malfunction may occur if there is other device generating high heat; the radiation will influence the product to increase its temperature. Do not install this product into the fully-sealed space except the case in which the internal ...

  • Page 40: Mounting On/Removing From A Din Rail

    — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 2. Mounting on/Removing from a DIN Rail This product should be set on DIN rail for operation. CAUTION The connection connector of the controller or modules have no locking mechanisms. Therefore, they might be moved over when inserting or removing cables, using the switches, or transferring the products.
  • Page 41 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) (1). Hang the product on the upper part of the DIN rail. (2). Press it to the lower side of the DIN rail. Push the hook up to lock the product on the DIN rail. —...
  • Page 42 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware)  How to Remove Pull down the hook to unlock. If the hook is stuck, use a slotted screwdriver to unlock. Fixed hook Unlock the hook with a slotted screwdriver There are two ways to unlock the hook using a slotted screwdriver. Unlock it by one of the following.
  • Page 43 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) By rotating the screwdriver  Place the slotted screwdriver (the point should be smaller than 8mm) as shown in the figure. Rotate the screwdriver 90-degree in either direction. (1). With the hooks unlocked, pull the lower part of the product toward you. (2).

  • Page 44: Setting The Configurable Type Module

    — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 3. Setting the Configurable Type Module CAUTION Always confirm the PWR-LED is turned off before setting or removing the modules  Always check the module is firmly fixed on DIN rail with hooks when setting the product. ...
  • Page 45 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) Engage the side rail of the setting module to the side rail of the controller (or another module) that is already mounted. When the rails fit, slide the setting module all the way toward the DIN rail. Module side rail 山路を登りながら...
  • Page 46 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware)  How to Remove First, slide the attached end cover from the configurable type module to remove it. Unlock the hooks of the module. If the hooks are stuck, use a slotted screwdriver to unlock. Unlock the hook with a slotted screwdriver There are two ways to unlock the hook using a slotted screwdriver.
  • Page 47 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) By rotating the screwdriver  Place the slotted screwdriver (the point should be smaller than 8mm) as shown in the figure. Rotate the screwdriver 90-degree in either direction. With the hooks unlocked, pull the module toward you. Put back the end cover to the controller.

  • Page 48: Connecting To An External Device

    — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 2. Connecting to an External Device Use the supplied connector plug to connect the product to an external device. Connection cable Power Supply The supplied connector External Device The following example describes how to make the connecting cable with a supplied connector. Example of making the connecting cable with a 3-pin connector Applicable wires : AWG20 - 16 Strip off approximately 7mm (plus or minus 0.5mm) of the covered part of a cable and insert it...
  • Page 49 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) ATTENTION Ne tirez pas sur le câble de la fiche du connecteur pour retirer la fiche, vous risquez de briser  le fil. Saisissez toujours le connecteur pour le retirer. Utilisez un couple de 0,19 N·m pour le connecteur présent. ...

  • Page 50: Cable Connection

    Use copper wires that tolerate a temperature of 75 °C or higher. Recommended power supply is the optional products of the CPS-PWD-30AW24-01 or CPS-PWD- 90AW24-01(CONTEC). CAUTION If the maximum output current of the external power supply is smaller than the maximum consumption current of the product, the abnormal operations might occur due to the inrush current at the start-up time or the load fluctuation.

  • Page 51: Lan

    — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 2. LAN  LAN Cable Use the LAN cable described below Category Category 5 or better Cable Length Within 100 meters Refer to "LAN Port" in the page 28 for details of the LAN port and pin assignment. 3.
  • Page 52 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) Example Connection to a PC External device Example Connection to a Device External device  Baud Rate See the table below for the baud rate that can be set with the product. Error rate differs depending on the set baud rate.

  • Page 53: Digital Input

    — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 4. Digital Input  Digital Input Cable Use the digital input cable described below. Cable Use copper wires that tolerate the temperature of 75 °C and higher. Applicable wire AWG28 - 16 Cable Length The length differs depending on the actual use environment.

  • Page 54: Digital Output

    — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 5. Digital Output  Digital Output Cable Use the digital output cable described below. Cable Use copper wires that tolerate the temperature of 75 °C and higher. Applicable wire AWG28 - 16 Cable Length The length differs depending on the actual use environment.
  • Page 55 — — Installation CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) Example of connecting to the LED The corresponding LED lights up when you output "1" into the appropriate bit. The corresponding LED turns off when you output "0" into the appropriate bit. Output pin (+) External 5.1kΩ...

  • Page 56: Appendix

    Appendix This section lists the specifications and the physical dimensions of the product, and the details of model name. — 56 —...

  • Page 57: Specifications

    — — Appendix CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 1. Specifications 1. Specifications Function Specifications Item CPS-MCS341-DS1-111 CPS-MCS341-DS1-131 ARM Cortex-A8 600MHz Memory On Board 512MB DDR3 SDRAM On-Board 32MB NOR Flash On-Board 64MB NOR Flash for OS for OS Transmission standard 10BASE-T/100BASE-TX The number of channels Connector...
  • Page 58 — — Appendix CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) Item CPS-MCS341-DS1-111 CPS-MCS341-DS1-131 can be done by software) Output type Semiconductor relay output Output isolation Semiconductor relay isolation Output voltage resistance 1000V The number of output 4 *usable as digital input or digital output signal channels Maximum output 13.2V/100mA...
  • Page 59 — — Appendix CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) Installation Environment Requirements Item CPS-MCS341-DS1-111 CPS-MCS341-DS1-131 Operating ambient temperature -20 - +60°C *4 Operating ambient humidity 10 - 90%RH (No condensation) Non-operating ambient -20 - +60°C temperature Non-operating ambient humidity 10 - 90%RH (No condensation) Floating dust particles Not to be excessive Corrosive gases...

  • Page 60: Power Requirements

    Quand vous remettez le courant, laissez le produit hors tension pendant au moins une  seconde (ou plus) du délai hors tension. Lorsque vous utilisez le produit avec CPS-PWD-90AW24-01 (de CONTEC), le délai permis de  chute instantanée de tension sera de 20 millisecondes ou moins.

  • Page 61: Physical Dimensions

    — — Appendix CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 2. Physical Dimensions 1. CPS-MCS341-DS1-111 94.7 44.7 [mm] — 61 —...

  • Page 62: Cps-Mcs341-Ds1-131

    — — Appendix CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 2. CPS-MCS341-DS1-131 94.7 44.7 [mm] — 62 —...

  • Page 63: The Details Of Model Name

    — — Appendix CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 3. The Details of Model Name Details of the model name are described below. CPS - MCS 3 4 1 - DS 1 - 1 1 1 CONPROSYS Series Item Description Model MCS Standard Configurable Type Model ARM Cortex A8 Memory...

  • Page 64: Battery Disposal

    — — Appendix CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 4. Battery Disposal 1. Battery Specification The product contains one battery and the details are as follows: Item Description Lithium primary battery Type BR2330A/HD Model Maker Panasonic Nominal Voltage 255mAh Nominal Volume 2.
  • Page 65 — — Appendix CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) Unhook the five tabs of the product to remove the body cover. Openings Cut the two holding metals with nippers and take off the battery. Battery Support CAUTION When disposing of the battery, please comply with your local municipal regulations and ordinances. ATTENTION Respecter les règles et les ordonnances municipales pertinentes lors de l’élimination de la batterie.

  • Page 66: Optional Products

    Optional Products This section lists optional items that can be used along with the product. — 66 —...

  • Page 67: Optional Products

    CPS-COM-1PC with RS-232C (contains 1port) CPS-COM-2PC with RS-232C (contains 2 ports) CPS-COM-1PD with RS-422A/485 (1channel) CPS-COM-2PD with RS-422A/485 (2 channels) CPS-COM-1QL with LoRa communication Visit the Contec website for the latest optional products. https://www.contec.com/ Website — 67 —...

  • Page 68: Customer Support And Inquiry

    Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. — 68 —...

  • Page 69: Services

    — — Customer Support and Inquiry CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the Contec website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages.

  • Page 70: Index

    Index — 70 —...
  • Page 71 — — Index CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) Revision History MONTH YEAR Summary of Changes October 2016 The First Edition June 2018 Changed the layout of the manual. — 71 —...
  • Page 72 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CPS-MCS341-DS1-111, CPS-MCS341-DS1-131 Reference Manual (Hardware) NA04505 (LYTF935) 11092018_rev5 [10302015]...
