Reference Manual
(Hardware)
Digital Output Module
CPSN-DO-08L
Digital Output Module Built-in power supply
CPSN-DO-08BL
CONTENTS
Introduction .................................................................. 4
Safety Precautions .................................................... 10
Product Nomenclature and Function ............... 16
Installation ................................................................... 20
Appendix ...................................................................... 32
Optional Products .................................................... 38
Customer Support and Inquiry ............................ 40
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Contec CON PROSYS nano CPSN-DO-08L
Summary of Contents for Contec CON PROSYS nano CPSN-DO-08L
- Page 1 Reference Manual (Hardware) Digital Output Module CPSN-DO-08L Digital Output Module Built-in power supply CPSN-DO-08BL CONTENTS Introduction ..............4 Safety Precautions ............ 10 Product Nomenclature and Function ....16 Installation ..............20 Appendix ..............32 Optional Products ............ 38 Customer Support and Inquiry ......40...
-
Page 2: Table Of Contents
Table of Contents Introduction ..............4 1. Related Manuals ..............................5 2. Check the Firmware Version ..........................6 3. About the Product ..............................7 4. Features ..................................8 5. Product Configuration List ..........................9 Safety Precautions ............10 1. Safety Information ............................... 11 2. Handling Precautions ............................12 1. - Page 3 Table of Contents Customer Support and Inquiry ........40 1. Services ..................................41 — 3 —...
-
Page 4: Introduction
Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. — 4 —... -
Page 5: Related Manuals
Included in the package Must read this after opening the This introduces related materials that (Printed matter) package. are made available on the CONTEC website, such as those for the included items, manuals, and software. Reference Manual for I/O Download from... -
Page 6: Check The Firmware Version
Before start using the product, visit our website to check the firmware version and update to the latest one if necessary. Updating firmware to the latest version will resolve troubles and stabilize the operation. https://www.contec.com/download/ Download Refer to the "Reference Manual (Software)" for CPU Units or "Reference Manual" for Modular USB I/O Units for the details of the firmware updating. -
Page 7: About The Product
— — Introduction CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 3. About the Product This product is an expansion module that adds a digital output interface to the CPU unit or USB I/O Unit - Module Type of the CONPROSYS nano series. CPSN-DO-08L has the opto-coupler isolated Output 8 channels (current sink output) whose response speed is 200µsec or less. -
Page 8: Features
— — Introduction CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 4. Features Opto-coupler isolated output (supporting current sink output) This product has the opto-coupler isolated Output 8 channels (current sink output) whose response speed is 200 sec or less. Internal circuit power supply (CPSN-DO-08BL only) The CPSN-DO-08BRL ‘s internal circuit has a built-in power supply, so no external circuit power supply is necessary. -
Page 9: Product Configuration List
— — Introduction CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 5. Product Configuration List The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product…1 10-pin Connector Please read the... -
Page 10: Safety Precautions
Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. — 10 —... -
Page 11: Safety Information
— — Safety Precautions CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely. DANGER Signal word used to indicate an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 12: Handling Precautions
— — Safety Precautions CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 2. Handling Precautions DANGER Do not use the product in locations exposed to a flammable or corrosive gas. It may cause explosion, fire, electrical shock, or malfunction. Do not allow the device to come into contact with foreign substances (metal particles, ... - Page 13 When removing connectors or cables, always unplug the power cables of the CPU unit or USB I/O Unit - Module Type first, and confirm the LEDs are turned off. Do not modify the product. CONTEC will bear no responsibility for any problems, etc., resulting from modifying the product.
- Page 14 When disposing of the product, follow the disposal procedures stipulated under the relevant laws and municipal ordinances. Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever (Including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein.
-
Page 15: Fcc Part15 Subpart B Class A Notice
— — Safety Precautions CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 1. FCC PART15 Subpart B Class A Notice NOTE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 16: Product Nomenclature And Function
Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. — 16 —... -
Page 17: Nomenclature Of Product Components
— — Product Nomenclature and Function CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 1. Nomenclature of Product Components Component names of the product are shown in the figure below. Name Function LED Indicator Displays the digital output status. Interface Connector This is a connector for digital output. Use the 10-pin connector, included in the package. -
Page 18: Description Of Product Components
— — Product Nomenclature and Function CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 2. Description of Product Components Components such as connectors, switches are described. 1. LED Indicator When all the digital outputs are OFF, the LEDs all turn off. The hexadecimal value (0x00) can be obtained with the software. -
Page 19: Interface Connector
— — Product Nomenclature and Function CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 2. Interface Connector This product has 8 channels of digital output. Use the 10-pin connector included in the package. Mounted Connector 10-pin European style terminal block (3.81mm pitch, 10 x 1 row) MC 1.5/10-G-3,81 P26 THR [Phoenix Contact] or equivalent Compatible Connector ... -
Page 20: Installation
Installation This section describes how to mount the product on a DIN rail or the wall, and to connect to an external device with a cable. — 20 —... -
Page 21: Install The Product
— — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 1. Install the Product 1. Installation Conditions Installation Orientation You can position the product in the orientation shown below. Other orientations could cause problems such as malfunction due to inadequate heat dissipation. Vertical installation (Installation angle 0°) Vertical installation with an angle of 90°... -
Page 22: Horizontal Installation
— — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) Horizontal installation Make sure to gain proper space between the product and devices that generate heat or exhaust air so that the ambient temperature stays in the range specified in the environment requirement. Also, the temperature range in the environment requirements varies depending on the installation orientation, so check the operating temperature range in "Specifications(Page 33)". - Page 23 — — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) CAUTION The product is an open-type device (a device designed to be housed inside other equipment) and must always be mounted inside a mechanical enclosure having enough strength. Note that although the ambient temperature is within the specified range, an operational ...
-
Page 24: Installation And Removal Of I/O Module And Blank Panels
— — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 2. Installation and Removal of I/O Module and Blank Panels CAUTION Always confirm the PWR-LED of the CPU unit is turned off before installing or removing the module. Installation procedure Paying attention to the horizontal orientation of the I/O module, insert the resin groove into the rail of the CPU unit or USB I/O Unit - Module Type that has been installed on a DIN rail or that has been screwed into place, and then push the I/O module in until it clicks. -
Page 25: Removal Procedure
— — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) Removal procedure Press in the hooks at the top and bottom of the I/O module, and then pull it toward you and out of the CPU unit or USB I/O Unit - Module Type that has been installed on a DIN rail or screwed into place. -
Page 26: Derating
— — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 2. Derating 1. Derating By Way of the Output Current The characteristic of derating by way of the output current is shown in the following figure. Use this product within the derating range. Failing to do so may lead to malfunctions. Characteristic of derating by way of the output current —... -
Page 27: Connecting To An External Device
— — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 3. Connecting to an External Device When connecting the product to an external device, use the supplied connector. When wiring the connector, strip off 8 mm ± 0.5 mm of the wire's covering, and then insert this stripped part into the connector's opening. -
Page 28: Cable Connection
— — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 4. Cable Connection 1. Digital Output Digital Output Cable Use the digital output cable described below. Cable Use copper wires that withstand the temperature of 75 °C and higher. Applicable wire AWG28 - 16 Cable Length Vary according to the environment where the product is used. - Page 29 — — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) Digital Output circuit (Current sink type) <CPSN-DO-08BL > This Product External device +12V External Load Output power supply 12 - 24VDC Zener Opto-coupler diode Load Output Zener Opto-coupler diode Fuse Minus common CAUTION When supplying power, all output will be OFF.
- Page 30 — — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) Example of connecting the product to LED < CPSN-DO-08L > (current sink type) The corresponding LED will be lit up when you output “1” into the appropriate bit. The corresponding LED will be turned off when you output “0” into the appropriate bit. <...
- Page 31 — — Installation CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) Example of connecting the product to TTL level input Example connection of Output and TTL level input (Current sink type) < CPSN-DO-08L > Example connection of Output and TTL level input (Current sink type) <...
-
Page 32: Appendix
Appendix This section lists the specifications and the physical dimensions of the product, and the details of model name. — 32 —... -
Page 33: Specifications
— — Appendix CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 1. Specifications Function Specifications Item CPSN-DO-08L CPSN-DO-08BL Output Output type Opto-coupler Isolation Open Collector Output (Current sink type) (negative logic) *1 Isolation Opto-coupler Isolation Voltage Resistance AC1000Vrms AC500Vrms Output rating Output Voltage 35VDC (Max.) Output Current 500mA (Max.) Residual Voltage with Output 0.5V or less (Output current ≤... -
Page 34: Installation Environment Requirements
— — Appendix CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) Installation Environment Requirements Item Description Operating ambient temperature *3 -20 - +60°C (Wall installation at an angle of 0°) -20°C to +55°C with a vertical installation at an angle of 90° to the left/right or with a plane installation Operating ambient humidity 10 - 90%RH (No condensation) -
Page 35: Physical Dimensions
— — Appendix CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 2. Physical Dimensions Physical dimensions of CPSN-DO-08L and CPSN-DO-08BL. Physical dimensions of CPSN-DO-08L and CPSN-DO-08BL. (with connector attached) — 35 —... -
Page 36: Relationship Between Logic Ports, Logic Bits And Connector Signals
This product can be combined with a CPU unit or USB I/O Unit - Module Type *1 to perform input/output using our device driver API-TOOL. The notation for input/output bits used in input/output with a CONTEC product is different for each product. For this reason, the inputs and the outputs are both renumbered into logical ports and logical bits from bit 0 to eliminate confusion about the layout of ports and bits and to make programming easier. -
Page 37: The Details Of Model Name
— — Appendix CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 4. The Details of Model Name Details of the model name are described below. CPSN - DO - 08 B L CONPROSYS nano Series Item Description Interface Digital Output Channel 8 Channels Model Type Built-in power supply Operating Voltage... -
Page 38: Optional Products
Optional Products This section lists optional items that can be used along with the product. — 38 —... -
Page 39: Optional Products
(Input: 100 - 240VAC, Output: 24VDC 1.3 A) CPS-PWD-90AW24-01 Fitting power supply 90W (Input: 100 - 240VAC, Output: 24VDC 3.8 A) *1 Available with our device driver API-TOOL. Visit the Contec website for the latest optional products. https://www.contec.com/ Website — 39 —... - Page 40 Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. — 40 —...
- Page 41 — — Customer Support and Inquiry CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the CONTEC website. Download https://www.contec.com/download/ You can download updated device driver, firmware, and differential manuals in several languages.
-
Page 42: Revision History
— — Revision History CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) Revision History MONTH YEAR Summary of Changes February 2018 The First Edition February 2020 Changed the layout of the manual. November 2023 Addition of "Relationship between logic ports, logic bits and connector signals" and options April 2024 Corrections due to changes in the bundle... - Page 43 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CPSN-DO-08L, CPSN-DO-08BL Reference Manual (Hardware) NA05980 (LYVQ217) 11152024_rev7 [01122018]...
