- Page 1 CONPROSYS Digital Output Module 16ch Sink Type CPS-DO-16L Digital Output Module 16ch Source Type CPS-DO-16RL Hardware Manual CONTEC CO., LTD.
-
Page 2: Check Your Package
Check Your Package Thank you for purchasing the CONTEC product. This product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product Configuration List - Product (One of the followings) [CPS-DO-16L, CPS-DO-16RL] …1... -
Page 3: Copyright
No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. -
Page 4: Table Of Contents
Component Functions ........................24 LED Indicator ..........................24 Isolation Digital Output Connector (DO00, DO01, DO02, DO03 DO04, DO05, DO06, DO07,DO10,DO11, DO12, DO13 DO14, DO15, DO16, DO17) ..........25 Stack Bus ............................ 26 System Reference Specifications ............................ 27 CPS-DO-16L, CPS-DO-16RL Hardware Manual... - Page 5 Physical Dimensions ........................29 List of Optional Products CPS-DO-16L, CPS-DO-16RL Hardware Manual...
-
Page 6: Before Using The Product
This product is an extension module with isolated digital Output interface and operates along with the stack type controller of our CONPROSYS series. CPS-DO-16L have the opto-coupler isolated Output16 channels (current sink output) whose response speed is 200µsec or less. -
Page 7: Customer Support
You can download updated driver software and differential files as well as sample programs in several languages. Note: For product information Contact your retailer if you have any technical questions regarding a CONTEC product or need its price, delivery time, or estimate information. Limited Two-Year Warranty CONTEC products are warranted by CONTEC CO., LTD. -
Page 8: Safety Precautions
When using the product at high altitudes, refer to the relational expression below to find an appropriate ambient temperature. The heat dissipation decreases due to air pressure drop and could lead to damages or a shorter product life. CPS-DO-16L, CPS-DO-16RL Hardware Manual... - Page 9 - Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever (Including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein.
- Page 10 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. EN55032 Class A Notice Warning: Operation of this equipment in a residential environment could cause radio interference. CPS-DO-16L, CPS-DO-16RL Hardware Manual...
- Page 11 1 Before Using the Product CPS-DO-16L, CPS-DO-16RL Hardware Manual...
-
Page 12: Setup
Figure 2.1. Unlock the fixed hooks-1 < 1 / 2 > (2) By using the screwdriver as leverage, move it upward in the direction of the arrow to unlock. Projection tip Figure 2.1. Unlock the fixed hooks-1 < 2 / 2 > CPS-DO-16L, CPS-DO-16RL Hardware Manual... - Page 13 The point of the screwdriver Figure 2.2. Unlock the fixed hooks-2 < 1 / 2 > (2) Rotate the screwdriver 90-degree in either direction. The point of the screwdriver Figure 2.2. Unlock the fixed hooks-2 < 2 / 2 > CPS-DO-16L, CPS-DO-16RL Hardware Manual...
-
Page 14: Affixing And Detaching Of The Stacking Modules
(3) Engage the rail on the left side of the stacking module with the rail on the right side of the mounted controller or of the other module. Then, slid the stacking module all the way toward DIN rail. Figure 2.3. Affixing the stacking module < 3 / 5 > CPS-DO-16L, CPS-DO-16RL Hardware Manual... - Page 15 (4) Lock the hooks of the stacking module. Figure 2.3. Affixing the stacking module < 4/ 5 > (5) Put back the end cover to the module. Figure 2.3. Affixing the stacking module < 5 / 5 > CPS-DO-16L, CPS-DO-16RL Hardware Manual...
- Page 16 (2) Unlock the fixed hooks of the module. Figure 2.4. Detaching the stacking module < 2 / 3 > (3) With the hooks unlocked, pull it toward you. Figure 2.4. Detaching the stacking module < 3 / 3 > CPS-DO-16L, CPS-DO-16RL Hardware Manual...
-
Page 17: Installation Conditions
Long-term usage might increase the temperature and lead to a malfunction or other troubles. - When using the product in a high temperature environment, its life time will be shorten. Perform the forced air cooling to counteract. CPS-DO-16L, CPS-DO-16RL Hardware Manual... - Page 18 2 Setup Spaces between the product and surrounding objects (ambient temperature exemplar) 50mm 50mm 50mm *The measurement points are shown as the circles in the figures above. Figure 2.6. Spaces between the product and surrounding objects (exemplar) CPS-DO-16L, CPS-DO-16RL Hardware Manual...
-
Page 19: Cable Connection
Removing the connector plug by grasping the cable can break the wire. Tightening torque of the attached connector is 0.19N⋅m. About a caution mark on the product: Please use copper wires that tolerate the temperature of 75 degrees Celsius and higher. 9±0.5mm Figure 2.7. Cable connection CPS-DO-16L, CPS-DO-16RL Hardware Manual... -
Page 20: Digital Output (Do)
2 Setup Digital Output (DO) Output equivalent circuit of digital Output interface unit is shown in Figure 2.8. for CPS-DO-16L, Figure 2.9. for CPS-DO-16RL. DO connects to the device controlled by the current drive such as control a relay or the LED. - Page 21 2 Setup This Product External device Plus Fuse Common External power supply 12 - 24VDC Zener Output Opto-coupler Load diode Zener Opto-coupler Output Load diode Figure 2.9. Digital Output circuit <CPS-DO-16RL > CPS-DO-16L, CPS-DO-16RL Hardware Manual...
-
Page 22: Example Of Connecting The Product To A Switch
The corresponding LED will be lit up when you output “1” into the appropriate bit. The corresponding LED will be turned off when you output “0” into the appropriate bit. Figure 2.10. Example connection to the switch <CPS-DO-16L > Plus Common... - Page 23 2 Setup CPS-DO-16L, CPS-DO-16RL Hardware Manual...
-
Page 24: Nomenclature And Functions
Nomenclature of Components Component names of the products are shown in Figure 3.1 and Figure 3.2. ③ ① ② Figure 3.1. CPS-DO-16L Nomenclature of components ③ ① ② Figure 3.2. CPS-DO-16RL Nomenclature of components (1) LED : Indicates the status of the product. -
Page 25: Component Functions
It indicates there is no outputting. It will light up upon outputting. DO10-DO17(Green) It indicates there is no outputting. *1 The module is inactive during the booting of the controller. Power will be supplied from the controller after the completion. CPS-DO-16L, CPS-DO-16RL Hardware Manual... -
Page 26: Isolation Digital Output Connector (Do00, Do01, Do02, Do03 Do04, Do05, Do06, Do07,Do10,Do11, Do12, Do13 Do14, Do15, Do16, Do17)
DO05, DO06, DO07,DO10,DO11, DO12, DO13 DO14, DO15, DO16, DO17) This product has 16 channels of digital output. Use the 10-pin connector, included in this package. Connector type : DEGSON 15EDGKC-3.81-10P-13-00AH (or equivalent) Table 3.2. Digital output connector <CPS-DO-16L> Pin No. Signal Name Meaning This connects the positive-side of the external power. -
Page 27: Stack Bus
This indicates the output signals. It connects the input signals from the other devices. DO17 This indicates the output signals. It connects the input signals from the other devices. Stack Bus It is used for power supply and communication to the stacking modules. CPS-DO-16L, CPS-DO-16RL Hardware Manual... -
Page 28: System Reference
*3 The fuse for overcurrent prevention is provided in the digital output circuit. Use a power supply that can supply a current of 2A and greater per common. CAUTION The maximum number of stacking modules operating along with the stack type controller is 16 and the total current consumption of the modules should be less than 3.3A. CPS-DO-16L, CPS-DO-16RL Hardware Manual... - Page 29 IEC60068-2-27-compliant) VCCI Class A、FCC Class A、 Standard CE Marking (EMC Directive Class A, RoHS Directive) *4 With the optional DIN rail fitting power supply : 10-55Hz (for details, see the specification of the optional power supply) CPS-DO-16L, CPS-DO-16RL Hardware Manual...
- Page 30 4 System Reference Physical Dimensions 25.2 94.7 [mm] Figure 4.1. Physical dimension <CPS-DO-16L > CPS-DO-16L, CPS-DO-16RL Hardware Manual...
- Page 31 4 System Reference 25.2 94.7 [mm] Figure 4.2. Physical dimension <CPS-DO-16RL > CPS-DO-16L, CPS-DO-16RL Hardware Manual...
- Page 32 (Input: 100 - 240VAC, Output: 24VDC 3.8 A) - CPS-PWD-30AW24-01 : DIN rail fitting power supply 30[W] (Input: 100 - 240VAC, Output: 24VDC 1.3 A) * Visit the Contec website regarding information on the optional products CPS-DO-16L, CPS-DO-16RL Hardware Manual...
- Page 33 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [01272017] [01272017] Management No. NA05500 Parts No.
