PARTS INCLUDED:
A [1]
HEADBOARD
B [1]
HEADBOARD BASE
C [1]
FOOTBOARD
D [2]
SIDE RAILS
E [1]
SLAT ROLL
F [2]
NIGHTSTAND
TOOLS
NEEDED:
Phillips Head Screwdriver
(Not included)
ASSEMBLY INSTRUCTIONS:
1. Attach the Headboard (A) to the Headboard Base (B)
using Flat Washer (1), Spring Washer (2), Bolt (3) and
Allen Key (4), and tighten (as shown in step 1).
2. Attach the Side Rails (D) to the Headboard (A) &
Footboard (C) using Flat Washer (1), Spring Washer (2),
Bolt (3), Allen Key (4), and tighten (as shown in step 2).
C A L L U M P L O A T I N G N I G H T S T A N D B E D
STEP 1
STEP 2
3
4
Page 1 of 2
NO.
ITEM
1
Flat Washer 5/16"
2
3
4
5
QTY.
DESCRIPTION
16pcs.
16pcs.
Spring Washer 5/16"
16pcs.
Bolt 5/16"x1-3/4"
Allen Key 4mm
1pc.
Wood Screw 8x30mm
4pcs.
