RH Teen CALLUM FLOATING NIGHTSTAND BED Quick Start Manual

Advertisement

PARTS INCLUDED

A [1] HEADBOARD
B [1] HEADBOARD BASE
C [1] FOOTBOARD
D [2] SIDE RAILS
E [1] SLAT ROLL
F [2] NIGHTSTAND

TOOLS NEEDED

Phillips Head Screwdriver (not included)

ASSEMBLY INSTRUCTIONS

1. Attach the Headboard (A) to the Headboard Base (B) using Flat
Washer (1), Spring Washer (2), Bolt (3) and Allen Key (4), and
tighten (Diagram 1).
2. Attach the Side Rails (D) to the Headboard (A) & Footboard (C)
using Flat Washer (1), Spring Washer (2), Bolt (3) and Allen
Key (4), and tighten (Diagram 2).
(B)
3
4
Page 1 of 2
NO.
ITEM
DESCRIPTION
1
5/16" Flat Washer
2
5/16" Spring Washer
3
5/16" x 1-3/4" Bolt
4
4mm Allen Wrench
5
8x30mm Wooden Screw
(A)
(D)
QTY.
16pcs
16pcs
16pcs
1pc
4pcs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CALLUM FLOATING NIGHTSTAND BED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RH Teen CALLUM FLOATING NIGHTSTAND BED

  • Page 1 PARTS INCLUDED ITEM DESCRIPTION QTY. 5/16" Flat Washer 16pcs A [1] HEADBOARD B [1] HEADBOARD BASE 16pcs 5/16" Spring Washer C [1] FOOTBOARD 16pcs 5/16" x 1-3/4" Bolt D [2] SIDE RAILS E [1] SLAT ROLL 4mm Allen Wrench F [2] NIGHTSTAND 4pcs 8x30mm Wooden Screw TOOLS NEEDED...
  • Page 2 3. Lay the Slat Roll (E) in between the Side Rails (D) and use Wood Screws (5) to fasten 2 end slats to the side rails with a screwdriver. 4. Attach the Nightstands (F) to the Headboard (A) securely. Insert Flat Washer (1), Spring Washer (2), Bolt (3) into the holes in the Nightstands (F) and tighten using Allen Key (4) (Diagram 4).
