All RH TEEN beds are designed to meet the highest safety standards
and comply with all U.S. and Canadian beds and beds regulations.
Made in India
Distributed in the USA by
rhteen.com
Restoration Hardware
11640 Harrel St, Suite B
Distributed in Canada by :
Restoration Hardware Canada Inc.
1500-1055 West Georgia Street,
Vancouver, British Columbia V6E 4N7
W W W A A A R R R N N N I I I N N N G G G :
CUSTOMER SERVICE:
If you are missing parts or have any questions about this product, contact us first. You can also order
parts by writing to the address above. Include the product model number, color, and a brief description
of the part. Call 1-800-762-1751.
CARE & CLEANING:
D D D O O O N N N O O O T T T scratch or chip the finish. D D D O O O N N N O O O T T T use abrasive chemicals for cleaning. Dust often using a clean,
soft dry cloth. If the Bunk bed is to be stored, store in a cool dry place and carefully package all original
hardware to protect from loss.
W Y L I E
L O F T
READ ALL INSTRUCTIONS BEFORE ASSEMBLING THIS PRODUCT.
Keep instructions for future use.
Page 1 of 7
B E D
F U L L
Model No. #107788WNTLFULL
Advertisement
Table of Contents
Related Manuals for RH Teen WYLIE LOFT BED FULL 107788WNTLFULL
Summary of Contents for RH Teen WYLIE LOFT BED FULL 107788WNTLFULL
- Page 1 L O F T B E D F U L L All RH TEEN beds are designed to meet the highest safety standards and comply with all U.S. and Canadian beds and beds regulations. Model No. #107788WNTLFULL Made in India Distributed in the USA by rhteen.com...
- Page 2 IMPORTANT SAFETY INFORMATION FOR BUNK BED : Follow the information on the WARNINGS appearing on the upper bunk and structure and on the carton. DO NOT REMOVE WARNING LABEL FROM BED. Always use the specified size mattress on upper bunk or mattress support, or both to help prevent the likelihood of entrapment or falls.
- Page 3 ASSEMBLY INSTRUCTIONS PARTS LIST: (1) Ladder End Side Guardrail Post - 1 pc (2) Second Side Guardrail Post - 1 pc (3) Left End Panel -1 pc (4) Right End Panel -1 pc. (5) Metal Tube Connecting Bars -4 pcs.` (6) Top Bunk Platform Midrail -1 pc.
- Page 4 HARDWARE LIST : ITEM DESCRIPTION QUANTITY Allen Bolt 16 pcs. 1 pc. Hex Wrench Short Screw 8x20mm 36 pcs. Short Dome Head Screw 16mm 20 pcs. TOOLS NEEDED: TOOLS TOOLS NEEDED: NEEDED: Phillips Head Screwdriver (Not included) ASSEMBLY INSTRUCTIONS NOTE: 1.
- Page 5 STEP 1: Connect the Left End Panel (#3) by aligning the slots in metal tube section on Guardrail Posts (#1) (#2) lining up the position A/A - B/B marked. Use 4 x Allen Bolts(A) and Allen Wrench (B) provided. See Detail 1. Please do not completely tighten the bolts until final assembly is complete. D D D E E E T T T A A A I I I L L L 1 1 1 (#1) - (#2) (#3)
- Page 6 S S S T T T E E E P P P 3 3 3 : : : Attach Wylie Metal Tube Connector Bars (#5) to both ends by aligning the slots in the side Guardrail Posts - matching the marked position as A/A and B/B. Use 2 x Allen Bolts(A) and Allen Wrench (B) provided on each side.
- Page 7 S S S T T T E E E P P P 5 5 5 : : : The following size mattress and foundations are specified for use with this Bunk Bed UPPER BUNK MATTRESS DIMENSIONS: Upper Bunk Bed - 74”-75”L x 53.5”-54.5”W x 9”H UPPER BUNK PLATFORM: Consists of 2 pcs of platform 75”L x 24”W x 3/4”H Note : MATTRESS THICKNESS MUST NOT EXCEED MAX 9”...
