Overland Storage XchangeNOW ARCvault Series Remove & Replace Instructions

ARCvault
2U Chassis Assembly
Remove & Replace Instructions
This document describes how to remove and replace an
Overland XchangeNOW ARCvault 2U chassis assembly.
WARNING: To reduce the risk of electric shock or
damage to equipment, disconnect the power cord.
CAUTION: A bracket and screws secure the robotics for
shipment and MUST be removed before operating.
IMPORTANT: If possible, document the current settings
by printing out a Full Trace Log before swapping chassis.
Unpack the spare chassis
Tie-Down Kit
ESD Bag
End Cap
WARNING: Due to the weight of the unit, it is
recommended that at least two people be used to lift
the unit out of the box to prevent injury.
1. Open the top of the box
end caps.
2. Remove the Wire Tie-Down kit.
3. Lift the ARCvault out and set it on a secure surface.
Part Number 10400010-106 06/2008
®
Series XchangeNOW
Overview & Notes
Unpack Spare Chassis
(Figure 1) and prepare it to receive the magazines and drives from the old unit.
Spare Chassis
Carton
Figure 1. Unpacking the Spare Chassis
(Figure 1) and lift off the top
©2007-2008 Overland Storage, Inc.
®
Unpacking
Carefully unpack and verify that you have all the parts:
• Spare 2U chassis assembly with drives
• Wire Tie-Down kit
• Magazine Release Tool
• These remove & replace instructions
A Phillips screwdriver is also needed.
Electrostatic Discharge Information
A discharge of static electricity can damage micro-circuitry
or static-sensitive devices. To help prevent Electrostatic
Discharge (ESD), observe standard ESD precautions.
End Cap
Shuttle Bracket Hole
Front Bezel
Off Table
4. Remove the ESD bag.
CAUTION:
allow the front bezel or door to contact the table.
5. Remove the shipping screws underneath
a. Turn the unit onto its left side making sure the
front bezel does not touch the table.
Pull
Well-Nut
Screws & Well-Nuts
Must Be Removed
Do NOT turn the chassis upside down or
Screw
(Figure 1):
Page 1 of 4
